Wiring
Wiring diagram
See wiring diagram on page 3.
Tools
■ Screwdriver for slotted screws, size 2.5, completely insulated to VDE 0680
TRG 5-5...
Use four-core cable for wiring:
1. Connect terminal strip acc. to wiring diagram. Fig. 1, Fig. 2
2. You can connect additional equipment to the terminals marked in yellow and black
of the TRG 5-54, TRG 5-56 and TRG 5-58. Fig. 2
Commissioning
Use the following table indicating the resistance of the Pt 100 to ascertain the current
temperature of the fluid.
1. Connect the test wire direct to the terminal box.
2. Measure the resistance with an ohmmeter.
3. Find the corresponding value in the table below, read off the temperature and, if
necessary, determine the exact value by interpolation.
Measure fluid temperature
°C 0 10 20 30 40 50 60 70 80 90 100
Ω
/deg
10 0 100.00 103.90 107.79 111.67 115.54 119.40 123.24 127.07 130.89 134.70 138.50 0.385
100 138.50 142.28 146.06 149.82 153.57 157.32 161.04 164.76 168.47 172.16 175.84 0.373
200 175.84 179.51 183.17 186.82 190.46 194.08 197.70 201.30 204.88 208.46 212.03 0.361
300 212.03 215.58 219.13 222.66 226.18 229.69 233.19 236.67 240.15 243.61 247.06 0.350
400 247.06 250.50 253.93 257.34 260.75 264.14 267.52 270.89 274.25 277.60 280.93 0.338
500 280.93 284.26 287.57 290.87 294.16 297.43 300.70 303.95 307.20 310.43 313.65 0.327
600 313.65 316.86 320.05 323.24 326.41 329.57 332.72 335.86 338.99 342.10 345.21 0.315
700 345.21 348.30 351.38 354.45 357.51 360.55 363.59 366.61 369.62 372.62 375.61 0.304
800 375.61 378.59 381.55 384.50 387.45 390.38 0.295
Basic resistance values according to DIN 43760 for Pt 100
