3 TECHNICAL DATA
DN A B C
DIN 11850, Series 2 191700/191800
10 / 3 /
8
˝ 60 81 10
15 / 1 /
2
˝ 60 81 16
20 / 3 /
4
˝ 60 81 20
25 / 1˝ 65 81 26
32 / 1/ 1 /
4
˝ 70 81 32
40 / 1/ 1 /
2
˝ 75 82 38
50 / 2˝ 85 84 50
65 / 2 1 /
2
˝ 100 105 66
80 / 3˝ 110 109 81
100 / 4˝ 120 115 100
Figure 1
M 10
C
A
A
B
M 38 x 1,5
a ⇑
b ⇒
