Maintenance

– continued –

Torques in Nm

All torques are based at 20 °C room temperature.

Tools

■

Spanner A. F. 60, DIN 3113, form B

■

Spanner A. F. 24, DIN 3113, form B

■

Spanner A. F. 18, DIN 3113, form B

■

Torque spanner 25 – 130 Nm, ISO 6789
