Specifications
Get
ting Star
ted
Connections
Set
up
Pla
ybac
k
Remot
e Contr
ol
Multi-z
one
Inf
or
mation
Tr
oubleshooting
ENGLISH
Depending on the program source being played, it may not be possible
to achieve a satisfactory surround effect. In this case, try other modes
to achieve a sound field suited to your tastes.
w DSP Simulation Playback
The desired mode according to the program source and viewing
situation can be selected from among 7 DENON original surround
modes.
The surround parameters can be adjusted (vpage 76, 77) to
achieve an even more realistic, powerful sound field.
Selecting the surround mode
Select by turning or pressing [SIMU].[Selectable items]5CH / 7CH STEREOz1 : This mode is for enjoying stereo sound from all speakers.ROCK ARENA : This mode is for enjoying the atmosphere of a live concert in an arena.JAZZ CLUB : This mode is for enjoying the atmosphere of a live concert in a jazz club.MONO MOVIEz2 : This mode is for playing monaural movie sources with surround sound.VIDEO GAME : This mode is suited for achieving surround sound with video games.MATRIX : This mode lets you add a sense of expansion to stereo music sources.VIRTUAL : This mode is for enjoying surround effects using only the front speakers or headphones.z1: “5CH STEREO” is displayed when “Surround Parameter” – “SB CH Out” is “OFF”, and “Amp Assign” is set to “ZONE2” (vpage 35, 48).z2: When playing sources recorded in monaural in the MONO MOVIE mode, the sound will be off balance with a single channel (left or right), so input to both channels.Playing Multi-channel Sources (Dolby Digital, DTS, etc.)In the case of standard playback of multi channel sources, the AVR-1909 recognizes the format of the multi-channel audio input signal and automatically operates the appropriate decoder for surround sound.[Selectable items]STANDARD :Any of the surround modes in the “Display” column in the following table.The mode changes depending upon factors such as the• Input signal• Whether or not surround back speakersare being used.For details, see page 79.e Direct PlaybackSelecting the modeSelect by turning
or pressing [D/ST] .
[Selectable items]
DIRECT :
In this mode the signals bypass the tone adjustment circuitry for high
quality sound.
The sound is output to the same channels as the input signal.
Input signal Display
Analog signal /
PCM (2ch) /
Dolby Digital source /
DTS source /
Other 2-channel digital signals
DIRECT
PCM (multi ch)
MULTI CH DIRECT
M DIRECT + PLgx CINEMA
M DIRECT + PLgx MUSIC
M DIRECT 7.1
z 1 : This is displayed when the input signal is “DTS-ES Matrix 6.1”
and the AVR-1909’s “AFDM” setting is set to “ON”.
z 2 : This is displayed when the input signal is “DTS-ES Discrete
6.1”.
z 3 : This is displayed when the input signal is “DTS 96/24”.
z 4 : When a signal is input, the HD AUDIO indicator lights.
For details, see pages 78, 79.
Input signal Display
DOLBY DIGITAL
(other than 2ch) /
DOLBY DIGITAL EX
DOLBY DIGITAL
DOLBY DIGITAL EX
DOLBY DIGITAL+PLgx CINEMA
DOLBY DIGITAL+PLgx MUSIC
DOLBY DIGITAL Plus (z4) DOLBY DIGITAL +
DOLBY TrueHD (z4)
DOLBY TrueHD
DOLBY HD+EX
DOLBY HD+PLgx CINEMA
DOLBY HD+PLgx MUSIC
DTS (5.1ch) /
DTS-ES Discrete 6.1 /
DTS-ES Matrix 6.1 /
DTS 96/24
DTS SURROUND
DTS+PLgx CINEMA
DTS+PLgx MUSIC
DTS+NEO:6
DTS ES MTRX6.1 (z1)
DTS ES DSCRT6.1 (z2)
DTS 96/24 (z3)
DTS-HD (z4)
DTS-HD HI RES
DTS-HD MSTR
DTS-HD+NEO:6
DTS-HD+PLgx CINEMA
DTS-HD+PLgx MUSIC
PCM (multi ch)
MULTI CH IN
MULTI IN+PLgx CINEMA
MULTI IN+PLgx MUSIC
MULTI CH IN 7.1
NOTE
When the input signal is DOLBY TrueHD, DOLBY DIGITAL Plus ,DTS-
HD you cannot select DENON original surround mode.
r Stereo Playback
Selecting the mode
Select by turning or pressing [D/ST].[Selectable items]STEREO :This is the mode for playing in stereo. The tone can be adjusted.Sound is output from the front left and right speakers and subwoofer. Pages: 1 … 46 47 48 49 50 … 92 wrong Brand wrong Model non readable See also other documents in the category Denon Home Theater Systems: DHT-FS3 (28 pages) AVR-3310CI (22 pages) AVR-591 (2 pages) AVC-A1XV (70 pages) AVR-2500 (24 pages) AVR-890 (76 pages) AVR-2311CI (90 pages) AVR-1611 (78 pages) DHT-488XP (2 pages) AVR-1911 (2 pages) AVR-2309 (81 pages) DHT-486XP (2 pages) DHT-M330DV (60 pages) DHT-FS5 (2 pages) AVR-2310CI (78 pages) AVR-391 (68 pages) AVR-1804 (3 pages) DHT-788BA (2 pages) DTS-ES AVR-685 (2 pages) A/V SORROUND RECEIVER AVR-4806 (2 pages) DHT-391XP (2 pages) AVR-3600 (36 pages) MCS 90 (2 pages) DHT-589BA (2 pages) DHT-483XP (2 pages) DHT-484XP (2 pages) DHT-684XP (2 pages) Sitemap
