Page 5

Install Guide
Model: MIL-170TRM
5
Figure 2.RJ-45 Pinouts
F i b e r S p e c i fi c a t i o n s : S T c o n n e c t o r
• 1300 nm single-mode fiber
• 8 or 9/125
µ
m single-mode fiber
• Launch power: -19 dBm
• Receive sensitivity: -36 dBm
O p e r a t i n g C o n d i t i o n s
Table 2: Recommended Operation Conditions
Parameters
Minimum
Maximum
Operating Temperature
+5° C
+50° C
Humidity: Non-condensing
10%
95%
Signal Output Load
35 ohm
75 ohm
Supply Voltage
4.75 V
5.25 V
1 2
3 4
5 6
8
7
