Thank you for your order of Fat Baggers, Inc. Product.
PLEASE NOTE: FBI recommends that our products be installed by a professional technician to ensure an
accurate and safe installation for the rider.
Once you’ve read completely through these instructions and looked through all boxes to make sure you’ve
located all components, for technical assistance, call FBI (877) 324-2453.
IMAGE #10 With front and rear mounting hardware
in place and left loose, place FBI Mount into the
front mounting points then lower it onto the rear
points—the “legs” of the chrome mount are to split
the spacers.
IMAGE #12 Full
view of FBI Fixed
Trunk Mount set
into place
IMAGE #11 FBI Close-Up of
mount set into place.
IMAGE #13 Side view of FBI Fixed
Trunk Mount bolted in place.
IMAGE #14 Close-up view of FBI
Fixed Trunk Mount bolted in
place.
IMAGE #15 FBI Fixed Trunk
Mount with Tour Pak bolted on.
