Desa V)V36EN - Manual (Page 35)

108862-01C
For more information, visit www.desatech.com For more information, visit www.desatech.com
35
35
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 108075-02 Burner Assembly Base 1
2 108759-01 Burner Pan Assembly 1
3 11165 Screw #10 x 5/8 MD TR BLK 12
4 108763-01 Tube Burner 1
5 104506-19 Pan Burner Orifice #48 (Natural Gas) 1
104506-20 Pan Burner Orifice #56 (Propane/LPGas) 1
6 108866-01 Pilot Assembly (Natural Gas) 1
108866-02 Pilot Assembly (Propane/LP Gas) 1
7 11102 Screw #8-32 x 3/8 PPH Zinc 2
8 108755-01 Pilot Bracket 1
9 14543 Tube Burner Orifice #51 (Natural Gas) 1
14544 Tube Burner Orifice #59 (Propane/LPGas) 1
10 14528 Brass Elbow Fitting 1
11 14554 Tubing Assembly 1
12 14500 Brass Fitting 2
13 14569 Electronic Valve (Natural Gas) 1
14570 Electronic Valve (Propane/LP Gas) 1
14 14253 Flexible Gas Line 1
15 11107 Screw #10-32 x 1/4 PPH Zinc 4
16 26808 Valve Bracket 1
17 26827 Switch Bracket 1
18 11147 Screw #10-24 x 1/2 PPH Zinc 2
19 11186 Screw #8-32 x 1 Zinc 4
20 14115 Spade Tongue Connector 1
21 14120 Spade 1/4 Female Connector 4
22 14126 16 GA Green Wire (Ground) 1
23 14129 Transformer, 24V 1
24 14134 18 GA Black Wire 5
25 14149 Spade 1/4 Right Angle Connector 4
26 14301 Ignition Module SP745 1
27 17223 Magnet 2
28 23416 Electronic Components Board 1
29 108863-01 24" Supply Connect Plug 1
30 11201 Nut #8-32 Hex Zinc 4
31 109144-01 Air Baffle, 36" (Natural Gas Only) 2
32 108761-01 Grate Assembly 1
33 108754-01 Grate Base 1
PARTS LIST
Burner Assembly for Models (V)V36EN, (V)V36ENS, (V)V36ENH, (V)V36EP, (V)V36EPS, (V)V36EPH
PARTS LIST
BURNER ASSEMBLY FOR MODELS
(V)V36EN, (V)V36ENS, (V)V36ENH,
(V)V36EP, (V)V36EPS, AND (V)V36EPH
This list contains replaceable parts used in your fireplace. When
ordering parts, follow the instructions listed under Replacement
Parts on page 30 of this manual.
