www.desatech.com 118197-01C 1
VENTINg INSTALLATION
INSTRUCTIONS
Continued
Note: Install
restrictor into
inner collar of
fireplace as
shown.
Venting with Two 90° Elbows
Vertical (V
1
) horizontal (h)
' min. 6' max.
6' min. 1' max.
7' min. 18' max.
8' min. 0' max.
Note: Vertical (V
1
) + Vertical (V ) = 40' max.
Figure 23 - Vertical Venting
Configuration Using Two 90° Elbows
(Vertical Round High Wind Termination
Shown)
4° Elbow
Vertical Venting
V = 40' max.
Figure 24 - Vertical Venting
Configuration With No Horizontal Run
(Vertical Round High Wind Termination
Shown)
Note: Install
restrictor into
inner collar of
fireplace as
shown.
4° Elbow
