φ6” Bench Mount Model
No Description Qty Arm model
103.1028
(10ft. Arm)
Part Number
1
Joint 1
1 103.1028.1
2 Joint 2 1 103.1028.2
3 Joint 3 1 103.1028.3
4 Joint 4 1 103.1028.4
5 Joint 5 1 103.1028.5
6 Joint 6 1 103.1028.6
7 Joint 7 1 103.1028.7
8 Joint 8 1 103.1028.8
9
Friction insert I
70
2 103.1028.9
10
Friction insert II
60
2 103.1028.10
12 Tube I 160 1 103.1028.12
13 Tube II 160 1 103.1028.13
14
Reinforcing
element I 160
2 103.1028.14
15
Reinforcing
element II 160
1 103.1028.15
21 Spring II, l=190 2 103.1028.21
22
Outer sleeve
160
1 103.1028.22
23 Inner sleeve 160 1 103.1028.23
25 Orifice 160 1 103.1028.25
26 Axis I 1 103.1028.26
27 Axis II 1 103.1028.27
28 Lever 1 103.1028.28
29 Sleeve 2 103.1028.29
30 Support plate 1 103.1028.30
31
Screw with
mushroom head
M10x30-4.8
8 103.1028.31
32 Nut M10-5-C 8 103.1028.32
33a
Regular washer
10.5
10 103.1028.33a
34
Spring washer
Z10.2
8 103.1028.34
35
Screw with
mushroom head
M8x30-4.8
8 103.1028.35
36 Nut M8-5-C 9 103.1028.36
37
Regular washer
8.2
1 103.1028.37
38
Spring washer
Z8.2
9 103.1028.38
41
Spring washer
Z6.1
2 103.1028.41
42 Nut M6-5-C 2 103.1028.42
