Fix the LCD console drawer into the rack.
Complete the installation
Step 3
■
Insert the left and right rear mounting brackets into
the LCD console drawer.
Step
1
< 1.3 > Installation - How to install Installation Slides
Step 2
■
Measure the depth of the front and rear mounting rails.
■
Align each rear mounting bracket to a suitable length.
M6 screw, cage nut & cup washer x 8 are provided.
