33
103310
KEY PART NUMBER FOR
NO. VYD24P VYBD24P DESCRIPTION QTY.
1A 103334-01 – Log, Premium Oak 1
1B – 103335-01 Log, Premium Birch 1
2 098276-01 098276-01 Hex Head Plug, 1/8" NPT 1
3 098249-01 098249-01 Nut, M5 2
4 099553-01 099553-01 Pilot Shield 1
5 102774-01BR 102774-01BR Painted Base Assembly 1
6 102844-01 102844-01 Lower Bracket 1
7 102966-01 102966-01 Upper Bracket 1
8 098867-10 098867-10 Gas Regulator 1
9 102798-01 102798-01 Inlet Tube 1
10 102779-02 102779-02 Outlet Burner Tube 1
11 099056-17 099056-17 Burner Orifice Injector 1
12 102843-01 102843-01 Burner Clip 1
13 102772-01 102772-01 Burner 1
14 102568-06 102568-06 Control Valve 1
15 098508-01 098508-01 Valve Retainer Nut 1
16 098354-01 098354-01 Control Knob 1
17 102445-01 102445-01 Piezo Ignitor 1
18 099387-08 099387-08 Pilot Tube 1
19 098271-07 098271-07 Ignitor Cable 1
20 099059-02 099059-02 ODS Pilot 1
20-1 099594-01 099594-01 Ignitor Electrode 1
20-2 098593-01 098593-01 Thermocouple 1
21 M11084-38 M11084-38 Screw, Hex Head 11
(#8-18 x .38)
PARTS AVAILABLE — NOT SHOWN
100563-01 100563-01 Warning Plate 1
101055-02 101055-02 Lighting Instructions Plate 1
100565-01 100565-01 Warning Plate Fastener 1
100639-01 100639-01 Caution Decal 1
101449-04 101449-04 Control Position Decal 1
101137-02 101137-02 Hardware Kit 1
101416-16 101416-16 Information Video 1
GA6060 GA6060 Lava Rock 1
PARTS LIST This list contains replaceable parts used in your heater. When ordering parts, follow
the instructions listed under Replacement Parts on page 29 of this manual.
