RJ-45 P
IN
S
P E C I F I C A T I O N
When connecting your DES-1008D to another switch, a bridge or a
hub, a modified crossover cable is necessary. Please review these
products for matching cable pin assignment.
The following diagram and tables show the standard RJ-45
receptacle/connector and their pin assignments for the switch-to-
network adapter card connection, and the straight / crossover cable for
the DES-1008D-to-switch/hub/bridge connection.
RJ-45 Connector pin assignment
Contact Media Direct Interface Signal
1 TX + (transmit)
2 TX - (transmit)
3 Rx + (receive)
4 Not used
5 Not used
6 Rx - (receive)
7 Not used
8 Not used
The standard cable, RJ-45 pin assignment
