OWNER’S MANUAL
23 105191
PARTS LIST This list contains replaceable parts used in your heater. When ordering parts, follow the instructions
listed under Replacement Parts on page 21 of this manual.
KEY PART NUMBER FOR
NO. FVF18N FVF24N FVF30N DESCRIPTION QTY.
1 105186-01 105186-02 105186-03 One Piece Log Set 1
2 098276-01 098276-01 098276-01 Hex Head Plug, 1/8" NPT 1
3 099553-01 099553-01 099553-01 Pilot Shield 1
4 102775-02CK 102775-01CK 102775-01CK Painted Base Assembly 1
5 102844-01 102844-01 102844-01 Lower Bracket 1
6 102966-01 102966-01 102966-01 Upper Bracket 1
7 098867-11 098867-11 098867-11 Gas Regulator 1
8 102780-01 102780-01 102780-01 Outlet Burner Tube 1
9 102798-01 102798-01 102798-01 Inlet Tube 1
10 099056-20 099056-18 099056-18 Burner Orifice Injector 1
11 102843-01 102843-01 102843-01 Burner Clip 1
12 102963-01 102773-01 102773-01 Burner 1
13 102568-07 102568-07 102568-07 Control Valve 1
14 098508-01 098508-01 098508-01 Valve Retainer Nut 1
15 098354-01 098354-01 098354-01 Control Knob 1
16 102445-01 102445-01 102445-01 Piezo Ignitor 1
17 098249-01 098249-01 098249-01 Nut, M5 2
18 099387-08 099387-08 099387-08 Pilot Tube 1
19 098271-07 098271-07 098271-07 Ignitor Cable 1
20 103042-01 103042-01 103042-01 ODS Pilot 1
21 M11084-38 M11084-38 M11084-38 Screw, Hex Head (#8-18 x .38) 11
PARTS AVAILABLE — NOT SHOWN
100563-01 100563-01 100563-01 Warning Plate 1
101055-02 101055-02 101055-02 Lighting Instructions Plate 1
100565-01 100565-01 100565-01 Warning Plate Fastener 1
100639-01 100639-01 100639-01 Caution Decal 1
101449-04 101449-04 101449-04 Control Position Decal 1
101137-02 101137-02 101137-02 Hardware Kit 1
02016 02016 02016 Lava Rock 1
