INSTALLATION INSTRUCTIONS
DOOR REVERSAL
INSTRUCTIONS
If you find the direction of opening the door on your
appliance inconvenient, you can change it by following
the steps shown in the below diagrams.
To avoid personal injury to yourself and/or property, we
recommend someone assist you during the door reversal
process.
CAUTION
1) To access the lower hinge assembly, tilt back the
refrigerator cabinet. (Fig. A)
2) Remove both leveling legs located at the front of the
cabinet.
3) Remove the screws holding the lower hinge
assembly to the cabinet. (Fig. A)
4) Remove the main door assembly from the
refrigerator cabinet (open door and pull down).
5) Remove the screws from the middle hinge assembly,
then remove the hinge and freezer door.
6) Remove (unscrew) the top hinge pin. (Fig. B)
7) Re-install the main door top hinge pin on the
opposite side of the cabinet. (Fig. B)
8) Remove the door plug and door bushing located on
the top and bottom of each cabinet. (Fig. B)
9) Interchange positiones (i.e., door plug right side, door
bushing left side).
10) Re-install freezer door assembly on cabinet.
11) Re-install the middle hinge assembly on the
opposite side. (Fig.C)
12) Make sure the door assembly is properly aligned on the
cabinet before tightening the hinge screws.
13) Re-install the main door assembly on the cabinet.
14) Re-install the lower hinge assembly on the
opposite side, making sure to change the bushing
and screw on the opposite sides on the bottom
of unit.
15) Make sure the door assembly is properly aligned on the
cabinet before tightening lower hinge screws.
16) Re-install both leveling legs.
THIS PROCEDURE IS NOW COMPLETE.
2
Fig. C
Center Hinge
Fig. A
Fig. B
