Dolby Laboratories DVD Video - Manual (Page 3)

1 Disc loading tray
2 Tray OPEN/CLOSE key
3 Display
4 Remote control sensor
5 PLAY key
6 PAUSE/Still, Step key
7 STOP key
8 Standby indicator
FRONT OF PLAYER
english
7
INSTALLATION
ANALOG Y/C
ON / OFF
MAINS
Y U/Cr V/Cb CVBS A/V EUROCONNECTOR (RGB OUT) COAX OPTO
DIG. OUT
AUDIO OUTPUT
VIDEO OUTPUT
1 2 3 4 5 6 7 8 9
DVD 960 DVD / VIDEO CD / CD PLAYER
OPEN/CLOSE
PLAY PAUSE STOP
TIME TOTAL
1 • 2 • 3 • 4 • 5 • 6 • 7 • 8 • 9 • 10 • 11 • 12 • 13 • 14 • 15 +
CD
TRACK
1 2 3 4 5 7 6 8
1 Power supply
2 ON/OFF
3 S-Video
4 Component video (YUV); Video output
5 Video (CVBS); Video output
6 A/V Euroconnector
7 Audio R; Audio output R
Audio L; Audio output L
8 Coaxial Digital audio output
9 Optical Digital audio output
CAUTION
Do not touch the inner pins of rear-panel connectors.
Electrostatic discharge may cause permanent damage
to the unit.
REAR OF PLAYER
