Dual XD622W - Manual (Page 6)

6
XD622W OPERATION
General Operation
Press and hold DISP then press TUNE to select radio
frequency (tuner mode) or CD track/ elapsed time (CD player
mode) display priority (default). Clock is accessed by
pressing
DISP momentarily.
Press and hold DISP then press TUNE to select clock
display priority. Radio frequency or CD track/elapsed time is
accessed by pressing
DISP momentarily.
Programs unit to display clock/no clock when unit is off.
Press and hold
MODE then press PRESET 1 to turn clock
priority on/off.
Press and hold for more than 2 seconds to RESET the unit
upon initial installation or if abnormal operation occurs. The
RESET button is located behind the faceplate.
Press rotary encoder to select between Volume (default),
Bass, Treble, Balance & Fader.
Press rotary encoder until BASS appears
Rotate encoder left/right to adjust
(+6 maximum / -6 minimum)
Press rotary encoder until TRE appears
Rotate encoder left/right to adjust
(+6 maximum / -6 minimum)
Press rotary encoder until BAL appears
Rotate encoder left/right to adjust
(L12-0-R12) 00 represents equal balance.
Press rotary encoder until FAD appears
Rotate encoder left/right to adjust
(F12-0-R12) 00 represents equal fader.
Individual Bass and Treble settings are retained in memory
for AM, FM, Weatherband, CD and AUX modes.
Programmable
Display Priority
Programmable
Clock Priority
Reset
Audio
Bass
Treble
Balance
Fader
Source Audio Memory
