5. V VIID DEEO O//A AU UD DIIO O O OU UTT—These connect to the monitor’s video and audio inputs.
RED phono jack is Audio Right.
WHITE phono jack is Audio Left
YELLOW phono jack is Video
6. D DIIV VEER RSSIITTY Y A AN NTTEEN NN NA A IIN NP PU UTT—4 antenna input jacks are provided. The TV100 will automatically
pick the strongest of the 4 signal inputs.
7. 1 12 2 V VD DCC O OU UTT—The monitor can be powered by connecting to this power output jack—maximum
of 2A load.
R Reem mo ottee CCo on nttrro oll
1. P PO OW WEER R—Press to turn power on or off to the TV100.
2. TTV V//A AV V—Press to select between TV and AV mode.
3. A AU UTTO O—Press to enter auto search mode, then press the CCH H+ + button start searching for avail-
able TV channels.
4. CCH H+ +—Press to select the next TV channel up.
5. CCH H--—Press to select the next TV channel down.
6. D DSSP P—Press this button to display the current status (TV channel/AV)
7. 0 0– –9 9—These numeric buttons allow you to enter and view the TV channel number directly.
1
4
5
7
3
2
6
8
TV/AV POWER
CH- CH+ AUTO DSP
1 2 3 4
5 6 7
9 0 -/--
8
