Connecting your devices, Continued on next page), Vcr/dvd player speakers pc monitor – Dukane 8913-W User Manual
Page 6
4
RGB IN
AUDIO IN
Y C
b
/P
b
C
r
/P
r
COMPONENT VIDEO OUT
L R
AUDIO OUT
VIDEO OUT
L R
AUDIO OUT
L R
AUDIO OUT
S-VIDEO OUT
AUDIO OUT
RGB OUT
AUDIO OUT
USB
RGB OUT
RS-232C
HDMI OUT
Connecting your devices
Be sure to read the manuals for devices before connecting them to the projector.
Make sure that all the devices are suitable to be connected with this product, and
prepare the cables required to connect. Please refer to the following illustrations
to connect them.
VCR/DVD
player
Speakers
PC
Monitor
(continued on next page)
