21 104256
OWNER’S MANUAL
PARTS LIST This list contains replaceable parts used in your heater. When ordering parts, follow the
instructions listed under Replacement Parts on page 19 of this manual.
KEY PART NUMBER FOR
NO. VYS18P VYS24P DESCRIPTION QTY.
1 102968-01 102968-02 Back Log (#1) 1
2 102969-01 102969-02 Front Log (#2) 1
3 102970-01 102970-02 Crossover Log (#3) 1
4 102775-02CK 102775-01CK Painted Base Assembly 1
5 102844-01 102844-01 Lower Bracket 1
6 102966-01 102966-01 Upper Bracket 1
7 098867-10 098867-10 Gas Regulator 1
8 102798-01 102798-01 Inlet Tube 1
9 102780-03 102780-03 Outlet Burner Tube 1
10 099056-21 099056-19 Burner Orifice Injector 1
11 102843-01 102843-01 Burner Clip 1
12 102963-01 102773-01 Burner 1
13 102568-08 102568-08 Control Valve 1
14 098508-01 098508-01 Valve Retainer Nut 1
15 098354-01 098354-01 Control Knob 1
16 102445-01 102445-01 Piezo Ignitor 1
17 098249-01 098249-01 Nut, M5 2
18 099387-08 099387-08 Pilot Tube 1
19 098271-07 098271-07 Ignitor Cable 1
20 099059-02 099059-02 ODS Pilot 1
20-1 098594-01 098594-01 Ignitor Electrode 1
20-2 098593-01 098593-01 Thermocouple 1
21 M11084-38 M11084-38 Screw, Hex Head 11
(#8-18 x .38)
22 098276-01 098276-01 Hex Head Plug, 1/8" NPT 1
23 099553-01 099553-01 Pilot Shield 1
PARTS AVAILABLE — NOT SHOWN
100563-01 100563-01 Warning Plate 1
101055-02 101055-02 Lighting Instructions Plate 1
100565-01 100565-01 Warning Plate Fastener 1
100639-01 100639-01 Caution Decal 1
101449-04 101449-04 Control Position Decal 1
101137-02 101137-02 Hardware Kit 1
101416-16 101416-16 Information Video 1
GA6060 GA6060 Lava Rock 1
