The Static Mac Address Setting table displays the static Mac
addresses connected, as well as the VID. Press Delete to remove a
device. To add a new Mac address assignment, press Add Mac, then
select the assigned Port number, enter both the Mac Address and VID
and press Apply.

Security > Mac Address Table > Dynamic Forwarding Table

For each port, this table displays the Mac address of each packet
passing through the Switch. To add a Mac address to the Static Mac
Address List, click the Add checkbox associated with the identified
packet.

Figure 403 – Security > Dynamic Forwarding Table
