10
Instructions for the user
7.1 Hobs with knobs
7.1.1 Single cooking zones
Each knob shows the cooking zone it is for.
For example, there is one symbol identifies the knob that
controls the rear right-hand cooking zone.
To heat, turn the knob to the desired position (low to high).
Adjustment is continuous so that the appliance also operates
at any intermediate value.
7.1.2 Dual cooking zones
Each knob shows the cooking zone it is for.
For example, there is one symbol identifies the knob that controls the rear
right-hand cooking zone.
To heat the inner cooking zone, turn the knob to the desired position (low to high).
To heat both the inner and outer cooking zones, turn the knob to
and then
release. The knob will thus return to maximum . To adjust heating
intensity, rotate the knob anticlockwise to the desired position.
To return to heating of the inner cooking zone only, set the knob back
to 0 and then turn to the desired position
(low to high).
7.1.3 Description of symbols
REAR LEFT REAR RIGHT
FRONT LEFT FRONT RIGHT
7.1.4 Residual heat
The warning lights located between the cooking zones come on when the temperature of
one or more of the zones exceeds 60°C.
The lights go off upon temperature dropping to below approximately 60°C.
7.1.5 Switching off
To turn off, return the knob to 0.
