BCI LBS-16x16 User’s Manual

Link Bridge

TM

Universal 16x16 Optical/DVI/HDMI Matrix Switch

Broadata Technical Support, [email protected]

11

3.3 Telnet Control

Before attempting to use the telnet control, please ensure that
both the Matrix (via the ‘LAN /CONTROL’ port) and the PC/Laptop
are connected to the active networks.

Note: Please do not connect both the Matrix and the PC/Laptop
with a single CAT5e/6 cable together as it will not access the
telnet function.

To access the telnet control in Windows 7, click on the ‘Start’
menu and type “cmd” in the Search field then press enter.

Under Windows XP go to the ‘Start’ menu and click on “Run”,
type “cmd” with then press enter.

Under Mac OS X, go to Go-Applications-Utilities-Terminal. See
below for reference.
