PARTS LIST

To order replacement parts: provide your customer service representative with the product model

number and the part number located on the Parts List below, along with the quantity you require.

No.

Description

Q’ty

TRANSOM-A

Computer

1

SET

TRANSOM-A-1

Screw for fixing computer

4

PCS

TRANSOM-B-1

Rail

1

PCS

TRANSOM-B-2

Screw

4

PCS

TRANSOM-B-3

Stopper

1

PCS

TRANSOM-B-4

Wireless receiver for pulse

1

PCS

TRANSOM-B-5

Screw

2

PCS

TRANSOM-B-6

Screw

2

PCS

TRANSOM-B-7

Rear cover for rail

1

PCS

TRANSOM-C

Bracket for roller

1

SET

TRANSOM-C-1

Driving pulley

1

SET

TRANSOM-C-2

Roller

1

SET

TRANSOM-C-3

Screw

1

PCS

TRANSOM-C-4

Screw

1

PCS

TRANSOM-C-5

Nylon nut

1

PCS

TRANSOM-C-6

Nylon nut

1

PCS

TRANSOM-C-7

Spring washer

2

PCS

TRANSOM-C-8

Flat washer

2

PCS

TRANSOM-C-9

Bushing

2

PCS

TRANSOM-C-10

Bushing

2

PCS

TRANSOM-C-11

Screw

2

PCS

TRANSOM-C-12

Flat washer

1

PCS

TRANSOM-C-13

Flat washer

1

PCS

TRANSOM-D

Main frame

1

SET

TRANSOM-D-1

End cap for front stabililzer (L)

1

PCS

TRANSOM-D-2

End cap for front stabililzer (R) 1

PCS

TRANSOM-D-3

End cap for rear stabililzer

2

PCS

TRANSOM-D-4

Screw

1

PCS

TRANSOM-D-5

Cap

2

PCS

TRANSOM-D-6

Flat washer

1

PCS

TRANSOM-D-7

Nylon nut

1

PCS

TRANSOM-D-8

C-type ring

2

PCS

TRANSOM-D-9

Nut

2

PCS

TRANSOM-D-10

Transportation wheel

2

PCS

TRANSOM-D-11

Sensor box

1

PCS

TRANSOM-D-12

Screw

1

PCS

TRANSOM-D-13

Screw

4

PCS

TRANSOM-D-14

Sleeve

1

PCS

TRANSOM-D-15

Chain cover (L)

1

PCS

TRANSOM-D-16

Chain cover (R)

1

PCS

TRANSOM-D-17

Cover for chain cover

2

PCS

TRANSOM-D-18

Screw

5

PCS

TRANSOM-D-19

Cable wire (lower)

1

PCS

TRANSOM-D-20

Hand pulse wire

1

PCS

TRANSOM-D-21

DC wire

1

PCS

TRANSOM-D-22

Front cover for rail

1

PCS

TRANSOM-D-23

Computer bracket holder

1

PCS

TRANSOM-E

Handlebar

1

SET

No.

Description

Q’ty

TRANSOM-E-1

Handlebar foam

2

PCS

TRANSOM-E-2

Cap

2

PCS

TRANSOM-E-3

Velcro

1

PCS

TRANSOM-E-4

Inkle

1

PCS

TRANSOM-F

Flywheel

1

PCS

TRANSOM-F-1

Bearing

1

PCS

TRANSOM-F-2

Flywheel axle

1

PCS

TRANSOM-F-3

Bearing

1

PCS

TRANSOM-F-4

Bushing

1

PCS

TRANSOM-F-5

Nut

3

PCS

TRANSOM-F-6

Nut

2

PCS

TRANSOM-F-7

Fixing pin

2

PCS

TRANSOM-F-8

Fan

1

PCS

TRANSOM-F-9

Screw

4

PCS

TRANSOM-F-10

Driving belt

1

PCS

TRANSOM-G

Idler wheel

1

SET

TRANSOM-G-1

Curved washer

1

PCS

TRANSOM-G-2

Idler wheel with bearing

1

PCS

TRANSOM-G-3

Bearing

2

PCS

TRANSOM-G-4

Flat washer

1

PCS

TRANSOM-G-5

Screw

1

PCS

TRANSOM-G-6

Screw

1

PCS

TRANSOM-G-7

Flat washer

1

PCS

TRANSOM-G-8

Flat washer

1

PCS

TRANSOM-G-9

Nylon nut

1

PCS

TRANSOM-G-10

Spring for idler wheel

1

PCS

TRANSOM-H

Spring box

1

PCS

TRANSOM-H-1

Spring

1

PCS

TRANSOM-H-2

Flywheel axle

1

PCS

TRANSOM-H-3

Screw

1

PCS

TRANSOM-H-4

Fixing pin

1

PCS

TRANSOM-H-5

Cover of spring box

1

PCS

TRANSOM-H-6

Screw

4

PCS

TRANSOM-H-7

Bushing

1

PCS

TRANSOM-H-8

Nut

3

PCS

TRANSOM-H-9

Fixing pin

2

PCS

TRANSOM-H-10

Nut

2

PCS

TRANSOM-H-11

Bearing

1

PCS

TRANSOM-H-12

Iron ring(1)

1

PCS

TRANSOM-H-13

Screw

1

PCS

TRANSOM-H-14

Iron ring(2)

1

PCS

TRANSOM-H-15

Bearing

1

PCS

TRANSOM-H-16

One way bearing

1

SET

TRANSOM-H-17

Pulley

1

PCS

TRANSOM-H-18

Bearing

1

PCS

TRANSOM-H-19

Flat washer

1

PCS

TRANSOM-H-20

Bearing

1

PCS

TRANSOM-I-1

Slider bracket

1

PCS
