Beurer LB 88 - Manual (Page 22)

22
10. What if there are problems?
Problem Cause Solution
The operating loop
does not light up.
The mains cable is not plugged in. Connect the plug.
The control dial is at its minimum
position.
Turn the control dial clockwise towards the ma-
ximum position.
No LED display. The mains cable is not plugged in. Connect the plug.
The control dial is at its minimum
position.
Turn the control dial clockwise towards the ma-
ximum position.
Red LED display. The water level is too low; the water
tank is empty.
Fill the water tank.
No mist is produced. The LED display lights up red. Fill the water tank.
The LED display does not light up. Connect the plug.
The mist has a
strange smell.
The device is new. Remove the water tank, turn the screwed plug
and remove it.
Air the open, empty water tank in a cool, dry
place for twelve hours.
Stale or dirty water. Empty the base unit and the water tank and
clean them thoroughly.
Fill the water tank with fresh water.
Strange noise. The water tank is not positioned
correctly on the base unit.
Lift up the water tank and position it correctly
on the base unit.
The tank should sit tightly on the base unit.
Strange noise. There is too little water in the water
tank.
Fill the water tank.
The device is not level and unstable. Place the device on a firm, level surface.
Mist escapes from
underneath the
water tank.
The water tank is not positioned
correctly on the base unit.
Lift up the water tank.
Check whether the join between the base unit
and water tank is clean.
Clean if required.
Position the water tank correctly on the base
unit.
The tank should sit tightly on the base unit.
11. Technical data
Dimensions (L x W x H) Approx. 29.5 cm x 19.5 cm x 28 cm
Cable length Approx. 1.4 m
Weight when empty Approx. 2.24 kg
Mains voltage/frequency 220-240 V AC / 50/60 Hz
Nominal power 280 W
Room size Up to 48 m2
Maximum capacity Approx. 6 litres
Evaporation output 550 ml/hour
Signs and symbols The unit is double-protected and thus corresponds to protec-
tion class 2.
