Desa M36E - Manual (Page 23)

108796
23
23
For more information, visit www.desatech.com For more information, visit www.desatech.com
KEY M36E(B,H) M42E(B,H)
NO. VM36E(B,H) VM42E(B,H) DESCRIPTION
QTY.
1 14574 106543-01 Limit Switch 1
2 106638-01 107797-01 Insulation Pan 1
3 106639-01 107798-01 Fireplace Top Assembly 1
4 106641-01 107800-01 Fireplace Surround 1
5 106642-01 106642-01 Air Rod Retainer 1
6 106643-01 106643-01 Damper Rod Retainer 1
7 106651-01 107805-01 Panel Closure 2
8 106655-01 107809-01 Firebox Bottom 1
9 106656-01 107810-01 Firebox Surround 1
10 106657-02 107811-02 Air Separator 1
11 11408 11408 Bushing 2
12 106658-02 107812-02 Left Refractory, Std. Brick
(M36EB/M42EB)
1
108164-02 108169-02 Left Refractory, Herringbone
(M36EH/M42EH)
1
106658-01 107812-01 Left Refractory, Std. Brick
(VM36EB/VM42EB)
1
108164-01 108169-01 Left Refractory, Herringbone
(VM36EH/VM42EH)
1
13 106659-02 107814-02 Right Refractory, Std. Brick
(M36EB/M42EB)
1
108165-02 108170-02 Right Refractory, Herringbone
(M36EH/M42EH )
1
106659-01 107814-01 Right Refractory, Std. Brick
(VM36EB/VM42EB)
1
108165-01 108170-01 Right Refractory, Herringbone
(VM36EH/VM42EH )
1
14 106660-02 107816-02 Rear Refractory, Std. Brick
(M36EB/M42EB)
1
108166-02 108171-02 Rear Refractory, Herringbone
(M36EH/M42EH)
1
106660-01 107816-01 Rear Refractory, Std. Brick
(VM36EB/VM42EB)
1
108166-01 108171-01 Rear Refractory, Herringbone
(VM36EH/VM42EH)
1
15 106661-02 107818-02 Bottom Rear Refractory, Std.
Brick (M36E/M42E/M36EB/
M42EB)
1
108167-02 108172-02 Bottom Rear Refractory,
Herringbone (M36EH/M42EH)
1
106661-01 107818-01 Bottom Rear Refractory, Std.
Brick (VM36E/VM42E/
VM36EB/VM42EB)
1
108167-01 108172-01 Bottom Rear Refractory,
Herringbone (VM36EH/
VM42EH)
1
16 106662-02 107820-02 Bottom Front Refractory,
Std. Brick (M36E/M42E/
M36EB/M42EB)
1
108168-02 108173-02 Bottom Front Refractory,
Herringbone (M36EH/M42EH)
1
106662-01 107820-01 Bottom Front Refractory,
Std. Brick (VM36E/VM42E/
VM36EB/VM42EB)
1
108168-01 108173-01 Bottom Front Refractory,
Herringbone (VM36EH/
VM42EH)
1
17 106683-01 106683-01 Firebox Support Leg 2
18 106687-01 106687-02 Damper Can Collar 1
19 106691-01 107839-01 Screen Rod 2
20 106694-03 106694-04 Firebox Top Assembly 1
PARTS LIST
M36E(B,H),M42E(B,H), VM36E(B,H) AND
VM42E(B,H) MODELS
This list contains replaceable parts used in your heater. When
ordering parts, follow the instructions listed under Replacement
Parts on page 19 of this manual.
KEY M36E(B,H) M42E(B,H)
NO. VM36E(B,H) VM42E(B,H) DESCRIPTION
QTY.
PARTS LIST
M36E(B,H),M42E(B,H), VM36E(B,H) AND VM42E(B,H) Models
21 106699-01 106699-02 Transition 6" B-Vent Collar 1
22 106703-01 106703-01 Air Kit Door Assembly 1
23 106704-01 107822-01 Firebox Face 1
24 106948-02 107823-02 Smoke Deflector 1
25 107768-01 107824-01 Fireplace Top Insulation 1
26 107796-01 107796-02 Grate Assembly 1
27 107742-01 107742-02 Burner Pan 1
28 107795-01 107831-01 Burner Tube 1
29 107748-01 107748-01 Burner Bracket 1
30 107985-01 107985-02 Pilot Shield 1
31 901681-01 901681-01 Burner Clamp 1
32 11209 11209 Nut, #10-24 1
33 11147 11147 Screw, #10-24x1/2 1
34 901066-01 901066-01 Brass Air Mixer (NG) 1
901066-02 901066-02 Brass Air Mixer (LP) 1
35 901064-03 901064-08 Orifice (NG) 1
901065-08 901065-07 Orifice (LP) 1
36 108866-01 108866-01 Pilot - Natural Gas 1
37 108867-01 108867-01 Pilot Orifice (LP) 1
38 11102 11102 Screw, #8-32x3/8 2
39 14569 14569 Electronic Gas Valve (NG) 1
14570 14570 Electronic Gas Valve (LP) 1
40 107741-01 107741-01 Valve Bracket 1
41 14301 14301 Ignition Module 1
42 14253 14253 Manual Valve with Flex Hose 1
43 108769-01 108769-02 Extension Deflector 2
44 108005-03 108005-03 Wire Harness 1
45 108005-02 108005-02 Wire Harness 1
46 11418 11418 Push-On Nut 2
47 12105 107840-01 Screen 2
48 14123 14123 Strain Relief 1
49 14153 14153 Micro Switch 1
50 16405 16405 Collar Insulation 1
51 20023 20488 Starter Collar 1
52 20027 20027 Brick Liner Retainer 2
53 20042 20042 Air Kit Cover 1
54 20088 20088 Door Stop 1
55 20089 20089 Pivot Clip 2
56 20090 20090 Spring Clip 2
57 20280 20280 Top Spacer 4
58 21171 21171 Gas Knockout Cover 4
59 21379 24460 Gas Conduit 1
60 21380 — Gas Conduit 1
61 22912 22924 Draft Diverter 1
62 24353 24353 Box Assembly 1
63 11165 11165 Screw, #10x5/8
Mod. Tr. Blk. Ox
2
64 11107 11107 Screw, #10-32 x 1/4"
PPH Zinc MS
4
65 11109 11109 Screw #8-32 x 1/2" PPH Zinc 2
66 11186 11186 Screw #8-32 x 1" PPH Zinc 2
67 11201 11201 Nut, #8-32 Hex Zinc 4
68 14129 14129 Transformer 1
69 108864-01 108864-01 Strain Relief 1/2" Bushing 1
70 108863-01 108863-01 24" Supply Connect Plug 1
71 109098-01 109098-01 Wire Assy Elec. Harness 1
PARTS AVAILABLE NOT SHOWN
901155-01 901155-01 Vermiculite Bag 1
901156-01 901156-01 Pan Material 1
901157-01 901157-01 Lava Rock 1
22180 22180 Wall Switch Kit 1
