Internal Connectors
Chapter: Connectors
Beckhoff New Automation Technology CB1052
page 43
Description
Name
Pin
Name
Description
receive lane 15 +
PER15
A80
B80
GND
ground
receive lane 15 -
PER15#
A81
B81
N/C
reserved
ground
GND
A82
B82
N/C
reserved
Pinout PCI-express-x16 connector, translation SDVO signals (pins not used for this purpose are omitted):
Description
Name
Pin
Name
Description
DDPC-CLK
PRSNT1#
A1
B1
A14
B14
PET0
SDVOB-RED
A15
B15
PET0#
SDVOB-RED#
SDVO_TVCLKI
PER0
A16
B16
SDVO_TVCLKI#
PER0#
A17
B17
PRSNT2#
SDVO-CLK
A19
B19
PET1
SDVOB-GREEN
A20
B20
PET1#
SDVOB-GREEN#
SDVOB_INT
PER1
A21
B21
SDVOB_INT#
PER1#
A22
B22
A23
B23
PET2
SDVOB-BLUE
A24
B24
PET2#
SDVOB-BLUE#
SDVO_FLDSTALL
PER2
A25
B25
SDVO_FLDSTALL#
PER2#
A26
B26
A27
B27
PET3
SDVOB-CLK
A28
B28
PET3#
SDVOB-CLK#
A31
B31
PRSNT2#
SDVO-DAT
A33
B33
PET4
SDVOC-RED
A34
B34
PET4#
SDVOC-RED#
A37
B37
PET5
SDVOC-GREEN
A38
B38
PET5#
SDVOC-GREEN#
SDVOC_INT
PER5
A39
B39
SDVOC_INT#
PER5#
A40
B40
A41
B41
PET6
SDVOC_BLUE
A42
B42
PET6#
SDVOC_BLUE#
A45
B45
PET7
SDVOC_CLK
A46
B46
PET7#
SDVOC_CLK#
A48
B48
PRSNT2#
SDVO+PCIe
A81
B81
PRSNT2#
DDPC-DAT
