Datexx VOICE MAIL DV8 - Manual

TELEDEX Limited U.S.A. Warranty
TELEDEX INC. warrants these products to the original purchaser to
be free from defective material and workmanship.
The product will be repaired or replaced at our option, for up to
one year when returned with proof of purchase to the address below.
Include a check or money order for $5.00 to cover postage.
TELEDEX INC. 1 Atlas st. Kenilworth, NJ 07033
Warranty valid only in the U.S.A.
Printed in China 10/03
S TO P M O D E
DV8 Quick Start
Installing the Batteries
Place the unit face down,
slip off the battery cover and install
the 2 AAA batteries (supplied)
taking care to observe the proper polarity.
Please make sure to put the cover back on.
1
Setting Time/Date 2
Recording and Playing
Press the REC/PAUSE button . If the unit is not on,
this will turn the unit on.
Press it again, when you are ready to start recording.
If the unit is already on, pressing
REC /PAUSE will activate recording.
Use the same button to pause/restart your recording.
When you are finished with your message press
STOP.
To play back what you have just recorded, press PLAY.
3
Installing the Software
Auto-Launch
Boot up your computer and insert DV-8 CD supplied with this
package. The system should recognize the CD and take you
through the
DV8 Link Software installation steps.
This is an automatic procedure and you are quite safe in accepting
the install recommendations. Follow the on-screen prompts.
4
Manual Install
1. If the program does not auto-launch, right click on your start button
(lower left of your screen) and choose Explore.
Then navigate to your CD ROM drive
(It’s often the D drive. In any case, it’s likely to be the drive
showing “DV8” in its description.
2. Next navigate to the DV8Link folder on the DV8 Link CD and
double- click to open that folder.
3. Find Setup.exe and double click on that file to launch installation.
1. Files on the top of the DV8 Link
screen represent files stored
in the DV8.
2. Select the Name of the desired
file, and point to it clicking your
left mouse button. and you can
click on the
[Down Transfer]
button to move it down to store
on your computer.
3. Next, the program will ask you which audio format you would like
for this file, MP3 compressed file or a WAV file.
(See audio format descriptions on backside.)
4. Once you choose a format, the program automatically converts
the file to that format.
Sending a Voice Email
Talk and the Datexx DV8 digital recorder records the sounds in a special compressed
machine language that makes the voice files small and manageable.
It’s a brand new compression technology, developed by the Datexx R & D team,
specifically for the DV8.
During the process that transfers the DV8 files to your computer, the software will
automatically convert these files into
MP3 or WAV formatted files. This allows you
to send the recordings via Email using our special Email software (included).
You may elect to send the file as a
.WAV file or in the popular MP3 file format.
It works for the PC users, but is not designed for the Mac.
Transferring your Recording
Using the supplied USB cord, plug the DV8 unit into your computer.
NOTE: The connecting cable has a special connector for the
DV8 on one end. Your computer will also recognize the DV8 and
install the connection automatically.
(SEE DIAGRAM 1)
5
6
7
DIAGRAM 1
USB
To PC's USB Connector To USB Port
The .WAV file option takes approx. 4 times more memory to store and transmit than
the popular MP3 compressed format. (Try small files, like 10 seconds to 3 minutes
to start with)
When sending longer voice emails, it is suggested you utilize the MP3 format.
(See details in the owner's manual.)
www.datexx.com
Once the recorded file is transferred from the DV8, converted and
stored on your hard drive (the bottom screen) you are ready to send
your Voice Email.
About File Formats
Press MODE key and press it repeatedly till it shows CLOCK blinking.
Press PLAY to start setting the date,
the year is presented first.
Pressing + and – adjust the date.
Pressing
PLAY confirms your choice,
and moves to the next setting.
When all adjustments are complete,
Press
PLAY to confirm.
When you confirm the screen will
blink for a moment or two,
and then revert to normal.
R E C /P A U S E
+
_
H O LD
_
_ +
+
Once your DV8 is connected, the preinstalled DV8 Link Software will recognize
the unit, and on screen instructions will help you transfer the files to your PC.
Navigation
+ BUTTON
– BUTTON
PLAY
BUTTON
S TO
P
M O D E
S TO
P
M O D E
REC/PAUSE
BUTTON
MODE
BUTTON
1. On the My Computer screen (bottom), point to and click on name
of the desired file. The Send Via Email button light up.
2. Click on this button and your email program automatically launches.
3. In addition, your Voice email file is automatically attached to your
email message and it’s ready to send. Fill in the proper address
or addresses, and click
[Send] to send it to your colleagues or
family and friends.
See back side
P-1 P-2 P-3
HOLD
SWITCH
S TO
P
M O D E
Important!
Make sure to put [HOLD] switch ON (slide up)
when DV8 is not used. This will not only
protect DV8 from unwanted operation but
prolong battery life.
S TO
P
M
O
D
E
+ BUTTON
– BUTTON
PLAY
BUTTON
REC/PAUSE
BUTTON
MODE
BUTTON
HOLD
SWITCH
ERASE
BUTTON
A-B
BUTTON
MIC/
HEADSET
JACK
BUILT-IN
MIC
BUILT-IN
SPEAKER
USB
PORT
DV8
STOP
BUTTON
S TO P M O D E
