5
1 1 Door latch-When the door is closed
it will automatically shut off. If the
door is opened while the oven is
operating, the magnetron will
automatically shut off.
2 2 Door seal-The door seal maintains
the microwave within the oven cavity
and prevents microwave leakage
3 3 Oven cavity
4 4 Spatter shield-Protects the
microwave outlet from splashes of
cooking foods.
5 5
Safety interlock system-Prevents
the oven from operating while the
door is opened.
6 6 Door release button-Pushing this
button stops oven operation and
opens the door.
7 7 Glass cooking tray-Made of special
heat resistant glass. The tray must
always be in proper position before
operating.
Do not cook food directly on the tray.
8 8 Roller guide-Supports the glass
cooking tray.
9 9 Door screen-Allows viewing of food.
The screen is designed so that light
can pass through, but not the
microwaves.
FEATURES DIAGRAM
2
9 6
5 4 3 1
8 7
