Desa WMP20A - Manual (Page 25)

www.desatech.com 119344-01B 5
PARTs lIsT
This list contains replaceable parts used in your heater. When ordering parts, follow the
instructions listed under Replacement Parts on page 23 of this manual.
KEY
NO. PART NO.
DESCRIPTION QTY.
1 097159-04 Piezo Ignitor • • • • • • 1
107673-01 Front Panel • • • • 1
107676-01 Front Panel • • 1
3 103476-01 Grill Guard • • • • 1
103476-0 Grill Guard • • 1
4 100047-07 Gas Control Valve NG • 1
100047-08 Gas Control Valve LP • 1
0985-11 Thermostat Gas Valve LP • 1
0985-1 Thermostat Gas Valve NG • 1
0985-13 Thermostat Gas Valve LP • 1
0985-8 Thermostat Gas Valve NG • 1
5 104189-01 Bottom Glass Retainer • • • • 1
104189-0 Bottom Glass Retainer • • 1
6 09860-09 Glass • • • • 1
09860-10 Glass • • 1
7 ** Cabinet • • • • • • 1
8 107894-14 Deflector Assembly • • • • 1
107894-15 Deflector Assembly • • 1
9 09871-09 Ignitor Cable • • • • • • 1
10 09849-01 Nut • • • • • •
11 110803-01 ODS/Pilot Assembly • • • 1
110803-0 ODS/Pilot Assembly • • • 1
1 103446-0 Burner • • • • 1
103447-06 Burner • • 1
13 099387-03 Pilot Tubing • • • • 1
099387-05 Pilot Tubing • • 1
14 103845-05 Injector • • 1
103845-06 Injector • • 1
103845-07 Injector • 1
103845-08 Injector • 1
15 099066-0 Mounting Bracket • • • • • • 1
16 099415-17 Gas Regulator • • • 1
099415-18 Gas Regulator • • • 1
17 NJF 8C Hex Nut • • • • • • 1
18 103570-04 Outlet Tubing • • 1
10355-0 Outlet Tubing • • • • 1
19 10357-03 Inlet Tubing • • 1
10356-0 Inlet Tubing • • • • 1
0 11871-04 Baffle • • 1
11871-03 Baffle • • • • 1
1 098354-0 Control Knob • • 1
098508-01 Valve Retainer Nut • • 1
PARTS AvAILABLE — NOT SHOWN
110186-01 Thermocouple Kit • • • • • • 1
10064-03 Hardware Assembly • • • • • • 1
107888-01 Control Position Label • • • • • • 1
117103-03 Lighting Instruction Booklet • • • • • • 1
** Not a field replaceable part.
W
M
N
20
A
W
M
P
20
A
GWN20T
A
GWP20T
A
GWN30T
A
GWP30T
A
