INSTALLATION INSTRUCTIONS
NOTE
FOR TECHNICAL ASSISTANCE PLEASE CALL
760-788-2602 8:00 AM TO 5:00 PM PST.
ALL REPAIRS AND RETURNS ARE PROCESSED
THROUGH AVIONICS INNOVATIONS
ALWAYS FOLLOW PROPER INSTALLATION PRACTICES PER FAA ADVISORY
CIRCULARS (AC) 43.13B OR LATER FAA APPROVED REVISION.
1.
Select an appropriate location for the AI-6 FPD & AI-ARM
A. A load and stress analysis of the installation location is nessecary to ensure
adequate structural integrity. It is the responsbility of the installer to ensure the
structure is adequate for the installation of this unit.
2. Mount the AI-6 FPD & AI-ARM (Refer to Drawing attached to this manual)
3. Wire unit (Refer to Drawing attached to this manual)
A. Use RG59 for video signal. Do not split the video signal to the display. Spliting
the signal will result in a poor video signal for the AI-6 FPD & AI-ARM.
B. Use 20G MIL-W-22759/16 wire for power and ground wiring.
NOTE
Hardware
All hardware shall be of an approved aviation standard type and appropriate backing
plates are to be manufactured for security of the panel.
Use appropriate AN or MS screws or bolts with washers to install your A1-6 FPD & AI-
ARM. The monitor/arm utilizes four mounting holes. The lengths of the screws are
determined by the thickness of the structure the panel is being attached to.
Revision NC 10/4/2002
Page 6
Avionics Innovations, Inc
AI-6 FPD & AI-ARM Installation Manual
