7
DDA416-‐XLR Manual
Configuration DIP Switches
Provides routing for signal flow in the unit. See the DIP Switch Routing Table for settings:
SOURCE SELECTION FOR AES/EBU OUTPUTS 1, 2, 3 & 4
Selected
Source →
AES
INPUT 1
AES
INPUT 2
AES
INPUT 3
AES
INPUT 4
DIP
Switch 1
Down
Up
Down
Up
DIP
Switch 2
Down
Down
Up
Up
DIP
Switch 3
Down
Down
Down
Down
SOURCE SELECTION FOR AES/EBU OUTPUTS 5, 6, 7 & 8
Selected
Source →
AES
INPUT 1
AES
INPUT 2
AES
INPUT 3
AES
INPUT 4
DIP
Switch 4
Down
Up
Down
Up
DIP
Switch 5
Down
Down
Up
Up
DIP
Switch 6
Down
Down
Down
Down
SOURCE SELECTION FOR AES/EBU OUTPUTS 9, 10, 11 & 12
Selected
Source →
AES
INPUT 1
AES
INPUT 2
AES
INPUT 3
AES
INPUT 4
DIP
Switch 7
Down
Up
Down
Up
DIP
Switch 8
Down
Down
Up
Up
DIP
Switch 9
Down
Down
Down
Down
SOURCE SELECTION FOR AES/EBU OUTPUTS 13, 14, 15 & 16
Selected
Source →
AES
INPUT 1
AES
INPUT 2
AES
INPUT 3
AES
INPUT 4
DIP
Switch 10
Down
Up
Down
Up
DIP
Switch 11
Down
Down
Up
Up
DIP
Switch 12
Down
Down
Down
Down
AC Input
Connector for socket IEC 320/C13. Power cord is supplied. Note that voltage selection is via jumpers on main
circuit board. Units are supplied wired for 115VAC or 230VAC, as specified at time of order. Power transformer
primary windings are paralleled for 115VAC or wired in series for 230VAC. Internal jumpers allow field
modification if necessary. See below for voltage conversion instructions.
