APPENDIX B: External DC POWER SUPPLIES
• Input: Universal 100-240 VAC / 47-63 HZ input, without any slide switcher output: 12V /
0~5A
• Case Dimension: 120L X 60W X 38 H MM
• Efficiency: 78% is typical
• Safety: UL/CUL/GS/PSE/BSMI
• EMI: FCC/CE Class B, conduction and radiation has been met.
• High frequency design, less power consumption
• CEC law (energy efficiency) has been met
• Over voltage protection, short circuit protection
U
Input:
Voltage
Range: Universal 100-200 VAC, single- phase
Nominal: 100–120 VAC / 200-24-VAC
Frequency
47 – 63Hz
Current
1.5A Max
Inrush Current
30A Max/100VAC; 60A Max / 240VAC
Efficiency
78% minimum 9At normal line voltage, full Load)
U
DC Output:
Voltage
12.00V
Current
5A MAX
Regulation
Vo+-5%
Ripple- and Noise
200 mV Max
Total Power
60 W Max
U
Protection:
Over Voltage Protection
V out (110% - 140%)
Short Circuit Protection
Automatic recovery after short circuit fault
removed
