The latest technical developments
are constantly being incorporated
into Durst products. Illustrations and
descriptions are therefore subject to
modification. All rights reserved on
images and illustrations.
© Durst Phototechnik AG, 05/2007
IX20805
Printing specifications
Printing system:
Patented Durst flatbed system with
Quadro® array technology for the finest
quality and the highest speed.
Resolution:
600 dpi
Colours:
Standard: CMYK
Optional: Light Cyan and Light Magenta,
White, clear varnish for special effects,
spot colours (on request).
Inks:
UV-curable pigment inks for interior and
exterior applications.
Ink supply:
Integrated ink tanks with 10 litre
capacity per ink, refillable during the
printing process. The refill inks are in
5 litre, non-returnable containers, easily
disposed in collapsed condition, thus
avoiding pollution to the machine and
the environment.
Software/RIP:
Durst Rho Linux software for very fast
processing with minimum storage
capacity on the hard disk. External
Caldera RIP Server (GrandRip+)
Productivity:
up to 120 sheets/hour
(125 x 80 cm/4 x 2,6 ft.) with Continuous
Board Printing Option
Media specifications
Media types:
Wide range of uncoated and coated
materials – also textured surfaces such
as hard foam sheets, soft foam sheets,
aluminium, acrylic glass, polycarbonate
sheets etc.
Maximum printing width:
250 cm (8 ft.)
Maximum printing length:
Only restricted by media length
Maximium thickness:
Standard: 40 mm (1.58 in.)
Industrial Version: 70 mm (2,75 in.)
Maximum media weight on belt:
Standard: up to 50 kg
Industrial Version: up to 70 kg
Smallest sheet size:
DIN-A3 – 29.7 x 42 cm (12 x 17 in.)
Registration of materials:
Materials are registered at the leading
edge by means of fibre optic sensors or
alternatively by mechanical front stops.
Parallel and continuous loading of sheets
is optional. An encoder measures the
transport sequences, ensuring utmost
precision in image alignment.
Location requirements
Space requirement:
min. 8 x 6 m (26 x 20 ft.)
Maximum height:
2.400 m (8.000 ft) above sea level
Temperature range:
+15 °C to +30 °C (+59°F to 86°F)
non-condensing
Relative air humidity:
25 - 80 % non-condensing
General specifications
Dimensions:
Width: 585 cm (230 in.)
Length with roll tables: 460 cm (181 in.)
Length without roll tables: 190 cm (75 in.)
Height: 195 cm (77 in.)
Weight:
Approx. 3.500 kg (7.700 lb)
Safety standards:
Complies with currently valid guidelines
Technical Data
