30
DTS-6D (3-drives) 35mm / 70mm System Parts List
D564 Logic break-out board (Dolby CP65)
D565 Logic break-out board (Dolby CP55, “generic”)
D567 Interface board (Dolby CP200, CP100, CP50)
D571 Logic break out board (UltraStereo JS Series)
D572 Audio break-out board (Dolby CP55, “generic”)
D574 Audio break-out board (Dolby CP45, CP65)
D575 Audio break-out board (UltraStereo JS Series)
D715 Logic break-out board (Dolby CP500)
D716 Logic break-out board (Dolby CP45)
D725 Dual input interface board, European studio application ( DTS6D / CP65 / dubber )
D587 DTS-6D 70mm fail-safe board (includes audio & logic cables, laminated sheet, offset film)
2503-0014-00 Analog output cable (for analog cinema processors), 6 feet long
D713 Digital output cable (for digital cinema processors), 4 feet long
2503-0014-00 Automation (logic) cable, 6 feet long (same part as the analog output cable)
D711 Interface cable, D567 (DTS-6D interface) to Dolby CP200, CP100, CP50 1/board
D712 Interface cable, D567 (DTS-6D interface) to Dolby CP200, CP100, CP50 2/board
D714 Interface cable, DTS-6D to Smart Mod 5, 2C, SR33, SR55, DM6
D706 Interface cable, DTS-6D to Smart Mod 6
2501-0001-00 Power cord, straight, detachable, standard bare-ended available, call DTS
2501-0002-00 Power cord, right angle, detachable
For single projectors:
D435-00
20 ft. Timecode cable single-ended available, call DTS
D435-01 30 ft. Timecode cable, standard
D435-02 40 ft. Timecode cable
D435-05 45 ft. Timecode cable
D435-06 60 ft. Timecode cable
For dual projectors:
D435-03
Timecode Y cable, 20 ft. / 30 ft, standard single-ended available, call DTS
D435-08 Timecode Y cable, 30 ft. / 40 ft.
D435-09 Timecode Y cable, 40 ft. / 50 ft.
D435-10 Timecode Y cable, 60 ft. / 60 ft.
D600-00 DTS 35mm reader head ( aux roller attached )
E108 Auxiliary roller assembly kit, 35mm
D600-02 DTS 70mm reader head ( aux roller attached )
E163 Auxiliary roller assembly kit, 70mm
Setup Equipment
E107
DTS Technician Kit ( includes demo disc & 35mm film, setup & empirical test discs )
6060-0005-0D 6-Track SETUP Disc Rev. DS1
6060-0006-00 Empirical Test Disc
6800-0002-02 DTS 70mm offset leader film
Mounting brackets for timecode reader heads (hardware included), permanent 35mm or 70mm:
D614
Standard bracket (for Century, Simplex, Ballantyne)
D616 Phillips AA bracket (Norelco)
D617 “L” bracket (Kinoton & Victoria)
D622 Front mount bracket (use with Dolby SR-D TM or Sony SDDS TM readers)
5006-0001-00 Cinemeccanica bracket (use with D614 standard bracket)
E102 70mm spacer kit (used to fit a 35mm reader in a 70mm space)
Mounting brackets for timecode reader heads (hardware included) switchable 35mm / 70mm:
D615
Universal bracket
D625 35mm/70mm standard bracket used with breakaway plates
D628 Adapter panel for D617 “L” bracket (so breakaway plates can be used)
D626 Breakaway (“spacing block”) plates for 35mm DTS reader head
D627 Breakaway (“spacing block”) plates for 70mm DTS reader head
