SoundMax SM-CMD2021 - Manual (Page 31)

31
Specification
General
Power supply
12 V DC
Current consumption/Fuse 10 A
Maximum power output 50 W x 4
Dimensions 178 x 51 x 178
Operation temperature range -20º - +60º
Electronic Shock Protection 45 sec. for CD, 120 sec for MP3
FM section
Frequency range
87.5 - 108.0 MHz
Usable sensitivity 3 uV
I.F. frequency 10.7 MHz
Programmable stations 18
AM section
Frequency range
522 kHz-1620 kHz
Programmable stations 12
Disc player
Supported formats DVD/DVCD/SVCD/VCD/CDDA/MP3/WMA/Picture-
CD/Photo-CD/JPEG/MPEG4(DivX)
Disc support DVD/DVD±R/±RW/CD/CD-R/CD-RW
Video system/Audio system Standard NTSC/PAL / 24 bit/96 KHz
Loading system Auto Loading
Mounting angle 0 to +/-30
Video specification
Video System 16:9 and 4:3
Video Output level 1.0Vp-p 75 ohms
Horizontal Resolution 500
Audio specification
Maximum Output 2Vrms(+/-3dB)
