Directed Electronics 28623T User Manual
Page 16
Directed Electronics Inc.
© 2005 Directed Electronics, Inc.
Make/model
Year
START
IGN 1
IGN 2
IGN 3/THEFT
ACC
BRAKE LIGHTS
TACH
ALARM DISARM
PARKING LIGHTS
HORN
NOTE
Pick-up Full size
1988-94
YELLOW
PINK
N/A
N/A
ORANGE
WHITE (+)
WHITE
N/A
BROWN (+)
BLACK(-)
Pick-up S-10
1995-02
YELLOW
PINK
WHITE 96+
See Note
ORANGE
WHITE (+)
WHITE
N/A
BROWN (+)
BLACK(-)
(1998/01 also equipped with passlock II)
Pick-up S-10
1986-94
VIOLET
PINK
N/A
N/A
ORANGE
WHITE (+)
WHITE
N/A
BROWN (+)
BLACK(-)
S-10 Blazer
1995-02
YELLOW
PINK
WHITE 96+
See Note
ORANGE
WHITE (+)
WHITE
N/A
BROWN (+)
BLACK(-)
(1998/01 also equipped with passlock II)
S-10 Blazer
1986-94
YELLOW
PINK
N/A
N/A
ORANGE
WHITE (+)
WHITE
N/A
BROWN (+)
BLACK(-)
Suburban
1995-02
YELLOW
PINK
WHITE 96+
See Note
ORANGE
WHITE (+)
VIOLET/WHITE
N/A
BROWN (+)
BLACK(-)
(1998/01 also equipped with passlock I
I)
Suburban
1992-94
Violet or Yel
PINK
N/A
N/A
ORANGE
WHITE (+)
WHITE
N/A
BROWN (+)
BLACK(-)
Tahoe
1995-02
YELLOW
PINK
WHITE 96+
See Note
ORANGE
WHITE (+)
WHITE
N/A
BROWN (+)
BLACK(-)
(1998/01 also equipped with passlock II)
Van
1995-01
YELLOW
PINK
WHITE
See Note
ORANGE
WHITE (+)
WHITE
N/A
BROWN (+)
BLACK(-)
(1998/01 also equipped with passlock II)
Van
1985-94
Violet or Yel
PINK
N/A
N/A
ORANGE
WHITE (+)
WHITE
N/A
BROWN (+)
BLACK(-)
Venture
1997-02
YELLOW
PINK
WHITE
See Note
ORANGE
WHITE (+)
WHITE
ORANGE / BLACK (-)
BROWN (+)
BLACK(-)
(1998/01 also equipped with passke
y III
Chrysler
300M
1999-02
YELLOW
BLUE / WHT
GRN / RED
Transponder
BLK / ORG
WHITE / TAN(+)
TAN /PINK
**GREEN / ORANGE (+)
BLACK / YELLOW (+)
BLK / RED
(-)
**equipped with transponder key
Cirrus
1995-99
YELLOW
BLUE
GRN/RED
N/A
BLK / ORG
WHT OR WHT/TAN
BLK / GRAY
**GREEN / ORANGE (+)
BLACK / YELLOW (+)
BLK / RED (-)
Optional tranponder key in late model
Concorde
1998-02
YELLOW
BLUE / WHT
GRN / RED
N/A
BLK / ORG
WHITE / TAN(+)
TAN /PINK
**GREEN / ORANGE (+)
BLACK / YELLOW (+)
BLK / RED (-)
**in driver kick panel
Concorde
1996-97
YELLOW
BLUE
RED / WHT
N/A
BLK / ORG
WHITE / TAN(+)
RED
**GRN/ORG OR WHITE (-)
BLACK / YELLOW (+)
BLK / RED (-)
**in driver kick panel
Concorde
1993-95
YELLOW
BLUE
RED / WHT
N/A
BLK / ORG
WHITE / TAN(+)
RED / YEL
**GREEN / ORANGE (-)
BLACK / YELLOW (+)
BLK / RED (-)
**in d
river kick panel
Imperial
1990-95
YELLOW
BLUE
N/A
N/A
BLK / ORG
WHITE / TAN(+)
BLK / GRAY
N/A
BLACK / YELLOW (+)
BLK / RED (-)
Le Baron Coupe
1990-94
YELLOW
BLUE
N/A
N/A
BLK / ORG
WHITE / TAN(+)
BLK / GRAY
N/A
BLACK / YELLOW (+)
BLK / RED (-)
LeBaron Conver.
1990-95
YELLOW
BLUE
N/A
N/A
BLK / ORG
WHITE / TAN(+)
BLK / GRAY
N/A
BLACK / YELLOW (+)
BLK / RED (-)
Lebaron Sedan
1993-94
YELLOW
BLUE
N/A
N/A
BLK / ORG
WHITE / TAN(+)
GRAY / BLU
N/A
BLACK / YELLOW (+)
BLK / RED (-)
LHS
1999-02
YELLOW
BLUE / WHT
GRN / RED
Transponder
BLK / ORG
WHITE / TAN(+)
TAN /PINK
**GREEN / ORANGE (+)
BLACK / YELLOW (+)
BLK / RED (
-)
**equipped with transponder key
LHS
1994-98
YELLOW
BLUE
RED / WHT
N/A
BLK / ORG
WHITE / TAN(+)
RED
**GRN / ORG OR WHT (-)
BLACK / YELLOW (+)
BLK / RED (-)
**in driver ki
ck panel
LHS
1994-95
YELLOW
BLUE
RED / WHT
N/A
BLK / ORG
WHITE / TAN(+)
GRAY
**GREEN / ORANGE (-)
BLACK / YELLOW (+)
BLK / RED (-)
**in driver kic
k panel
New Yorker
1996-97
YELLOW
BLUE
RED / WHT
N/A
BLK / ORG
WHITE / TAN(+)
RED
**GREEN / ORANGE (-)
BLACK / YELLOW (+)
BLK / RED (-)
New Yorker
1994-95
YELLOW
BLUE
RED / WHT
N/A
BLK / ORG
WHITE / TAN(+)
GRAY
**GREEN / ORANGE (-)
BLACK / YELLOW (+)
BLK / RED (-)
**in dr
iver kick panel
Sebring
2001-02
YELLOW
BLUE
GREEN/RED
N/A
BLK/ORG &BLK/WHT
WHITE/TAN (+)
LT.GREEN/ORANGE (-)
BLACK/YELLOW (+)
BLK/RED (-)
**equipped with
transponder key
Sebring
1995-99
BLK / RED
BLK / WHT
BLU / BLK
N/A
BLUE
GREEN (+)
WHT / BRN
**GREEN/ORG OR GRN/WHT (-)
GREEN / WHITE (+)
GRN / RED(-)
**in driver kick panel
Sebring Conver.
1996-99
YELLOW
BLUE
N/A
N/A
BLK / ORG
WHITE / TAN(+)
BLK / GRAY
GREEN / ORANGE
BLACK / YELLOW (+)
BLK / RED (-)
**late m
odel are equipped with transponder key
Town & Country
2001-02
YELLOW
PINK/WHT
N/A
N/A - Transponder
N/A
WHITE/BLK
VIOLET/Light BLUE
RED/BLK
GREEN/BLK (-)
( note: this vehicle needs 180 ohm resistor on 2nd starter wire)
Town & Country
1996-00
YELLOW
BLUE
GREEN/RED
N/A
BLK/ORANGE
WHITE/TAN (+)
D BLUE/TAN
WHITE/RED (-)
BLACK/YELLOW (+)
BLACK (-)
Town & Country
1991-95
YELLOW
BLUE
BLK/ORG
N/A
BLK/WHITE
WHITE/TAN (+)
BLACK/GRAY
N/A
BLACK/YELLOW (+)
BLACK/RED
Dodge
Avenger
1995-99
BLK / RED
BLK / WHT
BLUE / BLK
N/A
BLUE
GREEN
WHT / BRW
**GREEN / WHT
GREEN / WHITE (+)
GRN / RED(-)
**in black 20 pin con
nector driver kick panel
Caravan
2001-02
YELLOW
PINK/WHT
N/A
N/A - Transponder
WHITE/BLK
VIOLET/Light BLUE
RED/BLACK (+)
GREEN/BLK (-)
( note: this vehicle needs 180 ohm resistor
on second starter wire)
Caravan
1996-00
YELLOW
BLUE
DGRN/RED
N/A
BLK/ORANGE
WHITE/TAN (+)
GRAY/BLUE
WHITE/RED (-)
L GREEN/RED (-)
BLACK/RED (-)
Caravan
1991-95
YELLOW
BLUE
BLK/ORG
N/A
BLK/WHITE
WHITE/TAN (+)
BLK / GRAY
N/A
BLACK/YELLOW (+)
BLACK/RED (-)
Colt
1996
BLK / YEL
BLK / WHT
BLUE / BLK
N/A
BLUE
GREEN (+)
WHITE
N/A
GREEN / WHITE (+)
GRN / RED(-)
Colt
1995
BLK / YEL
BLK / WHT
BLUE / BLK
N/A
BLUE
GREEN (+)
WHITE
N/A
GREEN / WHITE (+)
GRN / BLK (-)
Dakota
1997-02
BLUE / YEL
BLUE
Grn/Red 99+
N/A
BLK / ORNG
WHITE / TAN
WHITE(+)
**BLACK / ORNG (-)
BLACK / YELLOW (+)
BLK / RED (-)
**12 pin
blk connector behind driver dash
Dakota
1992-96
YELLOW
BLUE
BLK/ORNG
N/A
BLACK/WHITE
WHITE(+)
GRAY / BLK
N/A
BLACK / YELLOW (+)
BLK / RED (-)
Durango
1998-02
YELLOW
BLUE
Grn/Red 99+
N/A
BLK / ORNG
WHITE / TAN
BLK / GRAY
**GREEN / ORNG (-)
BLACK / YELLOW (+)
BLK / RED (-)
Late Mod
el Require resistor value to Disarm
Intrepid
1998-02
YELLOW
BLUE / WHT
GRN / RED
**TRANSPONDER
BLK / ORG
WHITE / TAN(+)
TAN / PINK
**GREEN / ORANGE (+)
BLACK / YELLOW (+)
BL
K / RED (-)
2000+ are equipped with Transponder key
Intrepid
1996-97
YELLOW
BLUE
RED / WHT
N/A
BLK / ORG
WHITE / TAN(+)
RED
**WHITE (-)
BLACK / YELLOW (+)
BLK / RED (-)
**at fact keyless mod
on top of dash
Neon
1995-02
YELLOW
BLUE
N/A
**TRANSPONDER
BLK / ORG
WHT OR WHT/TAN
BLK / GRAY
N/A
BLACK / YELLOW (+)
BLK / RED (-)
2000+ are equipped with Transponder key
Omni
1987-90
YELLOW
BLUE
N/A
N/A
BLK / RED
WHITE
BLK / YELLOW
N/A
BLACK / YELLOW (+)
BLK / RED (-)
Ram Pick-up
2002
YELLOW
BLUE
GREEN
ORANGE
BLK/WHT & BLUE
WHITE/TAN (+)
TAN/RED
LT.GREEN/ORG (-)
PURPLE/YELLOW
BLK/RED (-)
Ram Pick-up
1997-01
BLUE / YEL
BLUE
BLACK/ORG
N/A
BLACK/WHITE
WHITE / TAN
GRAY / BLU
**GREEN / ORNG (-)
BLACK / YELLOW (+)
BLK / RED (-)
**24 pin conn behind driver dash
Ram Pick-up
1994-96
YELLOW
BLUE
BLACK/ORG
N/A
BLACK/WHITE
WHITE / TAN
GRAY / BLU
N/A
BLACK / YELLOW (+)
BLK / RED (-)
Ram Pick-up
2002
YELLOW
BLUE
RED
GRN&ORG-Trans
BLU&BLK/WHT
WHITE / TAN
TAN/RED
LT.GREEN/ORG
PUR/YEL
BLK/RED (-)
NOTE: needs 1.4K ohm resistor for parking liths
Ram Van Wagon
1998-02
YEL / BRN
BLUE
BLACK/ORG
N/A
BLACK/WHITE
WHITE / TAN
GRAY
**BLACK / ORNG (-)
BLACK / YELLOW (+)
BLK / RED (-)
**12 pi
n blk conn-driver kick pan. (1998=Yel/Brwn)
Ram Van Wagon
1992-98
YELLOW
BLUE
BLACK/ORG
N/A
BLACK/WHITE
WHITE / TAN
GRAY
N/A
BLACK / YELLOW (+)
BLK / RED (-)
Shadow
1991-94
YELLOW
BLUE
N/A
N/A
BLK / ORG
WHITE
BLK / GRAY
N/A
BLACK / YELLOW (+)
BLK / RED (-)
Spirit
1989-94
YELLOW
BLUE
N/A
N/A
BLK / ORG
WHITE
BLK / GRAY
N/A
BLACK / YELLOW (+)
BLK / RED (-)
Stealth
1991-95
BLK / YEL
BLK / WHT
BLUE / BLK
N/A
BLUE
GREEN
WHT / BLK
*LT-GREEN (-)
GRN/WHT OR ORG (+)
GRN / BLK (-)
**in driver kick pa
nel
Stratus
2001-02
BLK/RED
DK GREEN
BLUE/RED
TRANSPONDER
BLUE/BLK
GRN/ORG
WHT OR WHT/RED
DISARMS WITH UNLOCK
GRN/WHT OR PNK/BLK
GRN/BLK (-)
Stratus
1995-99
YELLOW
BLUE
BLK/ORG
N/A
BLK / WHT
WHITE / TAN(+)
BLK / GRAY
*LT-GREEN / ORANGE(+)
BLACK / YELLOW (+)
BLK / RED (-)
*back o
f fuse junction block 270 Omhs resistance …
Viper
1995-02
YELLOW
BLUE
N/A
TRANS-99+
BLK / ORG
WHITE
GRAY / BLU
N/A
BLUE OR TAN (+)
BLK / RED (-)
..for disarrm needed
FORD
Excursion
2000
RED/BLUE
RED/BLACK
RED/BLACK
2ND GRY/YEL
RED/BLACK
BLK/LGRN(+)
L GREEN (+)
D.GREEN/PURPLE (-)
BROWN (+)
YEL/L GREEN (-)
Equi
pped with Transponder
Aerostar
1992-98
WHITE/PINK
RED/L GRN
GRAY/YEL
2ND GRY/YEL
BLK/LGRN(+)
L GREEN (+)
TAN/YELLOW
N/A
BROWN (+)
YEL/LGREEN
Areomax
1996-98
WHITE/PINK
RED/L GRN
GRAY/YEL
2ND GRY/YEL
BLK/LGRN(+)
L GREEN (+)
TAN/YELLOW
N/A
BROWN (+)
YEL/LGREEN
Aspire
1994-98
WHITE
BLUE
BLK/RED
N/A
GREEN
GREEN
WHITE
N/A
RED/BLACK (+)
RED/GRN (-)
Bronco
1992-96
RED/BLUE
RED/L GRN
GRAY/YEL
2ND GRY/YEL
BLK/LGRN(+)
L GREEN (+)
TAN/YELLOW
N/A
BROWN (+)
DARK BLUE (-)
Contour
1995-00
GRY/WHT
GREEN
N/A
TRANS-99 +
YELLOW
ORNG/YELLOW
WHT/BLACK
N/A
RED/BLUE (+)
BLK/BLUE (-)
Crown Victoria
1995-02
WHT/PINK
BRW/PINK
PINK/BLK
GRAY/YEL
BLK/GRN
LT-GREEN
TAN/LT-GREEN
May equipped with transp
BROWN (+)
YEL/GREEN (-)
Equipped with 2 GRAY/YEL external relay is required
Crown Victoria
>1994
WHT/PINK
RED/GREEN
BRW/PINK
GRAY/YEL
BLK/GRN
LT-GREEN
TAN/YELLOW
N/A
BROWN (+)
YEL/GREEN (-)
Equipped with 2 GRAY/YEL
external relay is required
Econoline
1992-01
WHITE/PINK
RED/L GRN
GRAY/YEL
2ND GRY/YEL
BLK/LGRN(+)
L GREEN (+)
TAN/YELLOW
D.GREEN/PURPLE (-)
BROWN (+)
YEL/L GREEN (-
)
Escape
2001-02
TAN/LT.BLU
LGRN/PURP
N/A
N/A - Transponder
BLK/LT.GRN
L GREEN (+)
LT.GREEN/BLK
BROWN (+)
YEL/L GREEN (-)
Equipped with Transponder
Escort zx2
1999-02
RED/WHT
BLUE
BLACK/RED
N/A
BLACK/WHITE
GREEN (+)
L.GREEN/RED
N/A
RED/BLACK (+)
GREEN/ORG (-)
Escort
1997-98
BLK/GRN
GRY/YEL
RED/GRN
N/A
RED/BLUE
GREEN
GREEN/RED
N/A
RED/BLACK (+)
GRN/ORNG (-)
98 & UP MAY equipped WITH TRANSPONDER KE
Y.
Escort
1994-96
BLK/BLUE
DK-BLUE
BLK/RED
N/A
BLK/WHT
DK-GREEN
YEL/DK-BLUE
N/A
RED/BLACK (+)
GRN/ORG
Excursion
2001-02
RED/BLUE
RED/BLACK
RED/BLACK
2ND GRY/YEL
RED/BLACK
BLK/LGRN(+)
WHITE/PINK
D.GREEN/PURPLE (-)
BROWN (+)
YEL/L GREEN (-)
Eq
uipped with Transponder
Expedition
1997-02
RED/BLUE
DBLUE/GRN
GRAY/YEL
RED/BLACK
BLK/LGRN(+)
L GREEN (+)
WHITE/PINK
D.GREEN/PURPLE (-)
BROWN (+)
D BLUE (-)
Equippe
d with Transponder
Explorer
1991-01
RED/BLUE
LGRN/PURP
GRAY/YEL
2ND GRY/YEL
BLK/LGRN(+)
L GREEN (+)
TAN/YELLOW
D GREEN/PURPLE (-)
WHITE/BLACK (+)
BLACK (-)
Eq
uipped with Transponder from 1998+
Explorer
2002
RED
RED/GRN
N/A
N/A - Transponder
GRN/LTGRN
L GREEN (+)
BLU/GRN
D GREEN/PURPLE (-)
BROWN (+)
YEL/GREEN
Equipped with Transpon
der from 1998+
F-150 / F-250
1994-02
RED/BLUE
DBLUE/GRN
BLACK/RED
2ND GRY/YEL
BLK/LGRN(+)
L GREEN (+)
RED/GREEN
GREEN/VIOLET
BROWN (+)
YEL/LGREEN (-)
F-250 / F-350
1994-02
RED/BLUE
RED/BLACK
GRAY/YEL
2ND GRY/YEL
BLK/LGRN(+)
L GREEN (+)
WHITE/PINK
D GREEN/PURPLE (-)
BROWN (+)
YEL/LGREEN (
-)
Mustang
1998-02
WHT/PINK
RED/GREEN
RED/BLACK
GRAY/YEL
BLK/GRN
RED/LT-GREEN
ORANGE/WHT
N/A
BROWN +
PPL/ORNG (-)
equipped with transponder/us
e relay for ing 3
Mustang
1994-98
WHT/PINK
TAN/WHT
GRY/YEL
GRAY/YEL
BLK/GRN
GREEN OR RED/GRN
TAN/YELLOW
DK-GREEN/PPL
BROWN (+)
YEL/LT-GRN
96 & UP MAY equippe
d WITH TRANSPONDER KEY.
Probe
1996-97
GREEN
BLK/PINK
BLK/RED
N/A
BLUE/YEL
WHT/GREEN
GREEN
N/A
ORANGE
GRN/ORNG (-)
2
Blue Sheet update 2002.xls
