Paxton Superchargers Dodge Durango User Manual

Page 15

3-3

P/N: 4809632

25SEP02 v1.0 Dodge Durango(4809632v1.0)

Fig. 3-9

Attach the oil line, again supporting the oil
jet at the top. (See Fig. 3-10.)

Fig. 3-10

Re-install the plastic undertray reusing the
seven plastic fasteners.

Locate the fuel pressure test port directly
under the dipstick on the passenger side fuel
rail. (See Fig. 3-11.) Remove the plastic cap
and place a rag over the port. Hold the rag
with one hand and depress the valve with a
small screwdriver to relieve fuel system
pressure. Use caution when prforming this
step to avoid getting fuel in your eyes.
Remove the valve core using a small screw-
driver or valve core removal tool.

Fig. 3-11

Attach the discharge tube so the injectors are
situated under the throttle linkage. (See Fig.
3-12.)

Fig. 3-12

Attach the straight end of the fuel line to the
fuel rail and the 90 deg. end to the injector
block. Tighten using a 9/16” wrench. (See
Fig. 3-13.)

Fig. 3-13
