ix
P/N: 4PFX020-010
©2007 Paxton Automotive
All Rights Reserved, Intl. Copr. Secured
26JAN07 v2.1 UnivSBFCarb(4PFXv2.1)
PART NO. DESCRIPTION QTY. PART NO. DESCRIPTION QTY
IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report any shortages or damaged
parts immediately.
1969 Mustang 351W Small Block
Ford, Passenger’s Side Carbureted
Part No. 1001843 (NOVI 1200) | Part No. 1001848 (NOVI 1500)
PARTS LIST S U P E R C H A R G E R S
1016122 S/C ASY, NOVI 1200, CW, CRV 1969 1
1016126 S/C ASY, NOVI 1500, CW, CRV 1969 1
2A038-370 S/C PULLEY Ø3.70" 8-GROOVE 1
2A048-575 BELT, 57.5" 1
4PFX117-069 S/C DRIVE ASY SBF, '69 351 1
4FA111-042 S/C BELT TENSIONER ASY, H.O. 1
4PFX017-069 SPACER, SBF C/P, '69 351 1
4PFX018-021 CRANK PULLEY, SBF CARB 1
7A375-250 3/8-16 x GR8 HX 3
7K375-040 3/8"AN960 FLAT WASHER, PLATED 3
8PM205-012 CARB.ENCL ASY, SBF CARB 1
8PM105-012 ENCL. MACH. ASY, SBF 1
8PM003-051 CARB CVR, PAXTON 1
7P500-087 PLUG BTNHD, AN -8 w/O-RING, BLK 3
7A312-078 5/16-18 x 3/4" HOSE 16
7P187-102 FITTING, -3 TO 1/4" HOSE 3
7P187-103 PLUG, -3 BUTTONHEAD w/O-RING 1
7P375-104 PLUG, OIL HOLE 3
7A312-252 5/16" STUD 4
7F312-024 6/16-24 JAM NUT 4
7J312-000 5/16" FLAT WASHER-SAE 4
7U100-003 O-RING, -3 4
7U100-008 O-RING, -8 3
8M001-018 GASKET, 90mm THROTTLE BODY 1
7C011-050 10-32 PLUG SCREW 1
7U100-020 10-32 GASKET 1
8M001-017 HOLLEY 4-BARREL BASE GASKET 2
7P250-084 1/4"NPT x 1/2" x 90° BARB 1
8M110-069 ASY, THROTTLE '69 351 MUSTANG 1
2A017-031 SPACER, THROTTLE ENCL. .313"ID 1
7C010-052 10-24 x 1/2" SS BHCS 6
7C010-077 10-24 x 3/4" SS BHCS 5
7C010-187 3/16" ROD END RH WITH NUT 1
7C010-188 3/16" ROD END LH WITH NUT 1
7C011-075 10-32 SCREW 1
7F010-001 NUT, THROTTLE 1
7F010-033 10-32 NUT 1
7J010-001 #10 FLAT WASHER 8
7J010-687 WASHER, THROTTLE 1
8M010-010 BRACKET, IDLE 1
8M010-040 THROTTLE ARM INNER 2
8M010-050 THROTTLE SHAFT 1
8M010-070 RETAINER, SPRING ENCL. 1
8M010-080 RETAINER, SPRING THROTTLE 1
8M010-090 SPRING, THROTTLE ENCL. 1
8M010-140 SHAFT, 5/16" HEX 1
7C010-251 .25" BALL, THROTTLE, 10-24 MT THRD 1
7F010-024 10-24 NYLOCK NUT 2
8M010-025 MORSE CABLE BRKT 1
8M010-180 BRKT, '69 MUSTANG THROTTLE 1
4PFX110-060 MTG PLATE ASY, PASS’S, SIDE '69 351 1
4PFX010-050 PRIMARY MTG PLATE 1
4PFX010-060 S/C MTG PLATE 1
2A017-101-400 SPACER, SBF MTG PLATE 2
2A017-104-400 SPACER, 351 SBF MTG PLT 2
2A017-101-121 SPACER, FORD ALTERNATOR 1
7A375-500 3/8-16 x 5" HXHD GR8 3
7A375-575 3/8-16 x 5.75" HXHD GR8 PLT 2
7A375-126 3/8-16 x 1.25" HXHD GR8 PLT 6
7A437-550 7/16-14 x 5-1/2" HXHD 1
7K375-040 3/8"AN960 FLAT WASHER, PLATED 11
4PFX130-351 OIL FEED LINE ASY, SBF CARB 1
7P125-004 1/8"NPT x 90° x -4 JIC FTG 1
7P250-034 1/4"NPT x 1/4"NPT STRT T 1
7P250-250 1/4"NPT STR x -4 JIC FTG 1
7U250-090-320 OIL FEED HOSE, 32" -4 x 90° 1
7U100-055 TIE-WRAP, 6" NYLON 2
4PFX130-036 OIL DRAIN ASY, SBF CARB 1
7P375-017 3/8"NPT x 1/2" BEADED HOSE BARB 1
7R001-008 #8 STNLS HOSE CLAMP 2
7U030-036 1/2" OIL DRAIN HOSE 1.5'
4PFX112-031 AIR DISCHARGE ASY, SBF CARB 1
4PFX012-031 MACH, DISCH TUBE SBF CARB 1
7PS350-200 SLEEVE, BLACK 3.5"ID x 2.0" LG 1
7PS350-275 REDUCER, BLK 3.5" - 2.75" 1
7R002-044 #44 SAE TYPE “F” SS HOSE CLAMP 1
7R002-056 #56 SAE TYPE “F” SS HOSE CLAMP 3
7U030-046 5/32" VACUUM LINE 2
8H040-175 FILTER, 1-3/4"ID MFRB 1
8D204-010 RACE BYPASS VALVE - BLACK 1
4PFX101-001 FUEL ASY, SBF CARB 1
7P125-016 1/8"NPT PLUG 1
7P250-043 1/4"NPT x 5/16" BARB 1
7P250-047 1/4"NPT x 3/8" BARB x 90° 1
7P250-141 -6 HOSE END, 90° 1
7P500-083 AN -8 HOSE END, STRAIGHT 1
7P500-084 MALE TEE -8, -6, -6 1
7P500-085 FITTING, -8 BULKHEAD w/O-RING 1
7P500-086 120° -8 TO 1/2" BARB 1
7P500-087 PLUG, AN -8 O-RING PORT 1
7P500-089 FITTING, -8 BULKHEAD NUT, BLK 1
7P500-377 AN-8 MALE SHORT -6 MALE STD 1
7R001-006 #6 STNLS HOSE CLAMP 4
7U030-046 5/32" VACUUM LINE 4.5
7U032-016 3/8" EFI FUEL HOSE HI-PSR 2.5
7U100-008 O-RING, -8 3
8H040-020 FUEL FILTER, INLINE 3/8" 1
8F001-120 FUEL PUMP, SBF CARB 120GPH, 6-PSI 1
4PFX020-010 INSTALLATION INSTRUCTIONS, SBF CARB 1
8H040-035 AIR FILTER, 3.5"FLG x 3.7"L OFFSET (NOVI 1200) 1
814040-045 AIR FILTER 3.75"FLG x 5"L (NOVI 1500) 1
008575 S/C STRT INFO PKG ASY PAXTON 1
8M110-100 HOLLEY 4150 FLOAT BOWL LINE ASY 1
8M110-120 DEMON FLOAT BOWL LINE ASY w/FTGS 1
ADDITIONAL PARTS NEEDED FOR COMPLETE INSTALLATION
1) HOLLEY 4150 OR DEMON STYLE MECHANICAL SECONDARY
CARBURETOR
