Network Configuration

This section is used to configure the network settings.

Advanced

→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit

Switch all ByPass Mode to
Enable/Disable after power on.

Network Configuration

Power_ON ByPass Mode

Power_OFF ByPass Mode

[ALL Disabled]

Power_ON ByPass Mode
Enables or disables the LAN module bypass mode after the system powers
on.

Power_OFF ByPass Mode
Enables or disables the LAN module bypass mode after the system powers
off.

SATA Configuration

This section is used to configure the SATA drives.

SATA Controller(s)

Enables or disables the SATA controller.

SATA Mode Selection

Configures the SATA as IDE, AHCI or RAID mode.

IDE

This option configures the Serial ATA drives as Parallel ATA

physical storage device.

AHCI

This option configures the Serial ATA drives to use AHCI

(Advanced Host Controller Interface). AHCI allows the storage

driver to enable the advanced Serial ATA features which will

increase storage performance.

Advanced

→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit

Enable or Disable SATA Port

SATA Controller(s)

SATA Mode Selection

SATA Test Mode

Aggressive LPM Suppor

SATA Controller Speed

Serial ATA Port 0

Software Preserve

Port 0

Hot Plug

External SATA

SATA Device Type

Spin Up Device

Serial ATA Port 1

Software Preserve

Port 1

Hot Plug

External SATA

SATA Device Type

Spin Up Device

[Enabled]

[AHCI]

[Disabled]

[Enabled]

[Default]

Empty

Unknown

[Enabled]

[Disabled]

[Hard Disk Drive]

[Disabled]

Empty

Unknown

[Enabled]

[Disabled]

[Hard Disk Drive]

[Disabled]

▲

▼
