21 104821
OWNER’S MANUAL
PARTS LIST
VP2600TB
This list contains replaceable parts used in your heater. When ordering parts, follow the
instructions listed under Replacement Parts on page 17 of this manual.
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 098304-01 Screw, #10 x 3/8" 2
2 098742-14 Front Panel 1
3 098238-07 Grill Guard 1
4 101108-01 Clip-Grill Guard 2
5 098198-04 Apron 1
6 M11084-26 Screw, #10 x 3/8" 9
7 098271-03 Ignitor Cable 1
8 098457-02 Reflector Assembly 1
9 099415-09 Regulator 1
10 098303-02 Screw, #6 x 3/8" 2
11 104617-11 Cabinet Assembly 1
12 097159-04 Piezo Ignitor, Snap-in 1
13 See Detail Burner Assembly 1
13-1 099218-07 Burner 1
13-2 099056-01 Injector-Plaque B 1
13-3 104818-02 Tubing-Valve to Burner 1
13-4 099056-25 Injectors-Plaques A and C 2
13-5 103256-01 Inlet Tubing 1
13-6 099387-02 Pilot Tubing-Valve to Pilot 1
13-7 103594-04 ODS/Pilot 1
13-8 098522-16 Control Valve 1
13-9 M11084-37 Screw, #8 x 1/4" 5
13-10 M11084-26 Screw, #10 x 3/8" 2
13-11 098514-01 Thermocouple 1
13-12 106842-01 Ignitor Electrode 1
14 099066-01 Mounting Bracket 1
15 104819-01 Regulator Bracket 1
PARTS AVAILABLE - NOT SHOWN
098305-01 Control Position Label 1
100642-01 Hardware Assembly
