8
Press AUDIO momentarily to select between Volume
(default), Bass, Treble, Balance, & Fader.
Press AUDIO until BAS appears then rotate encoder
left/right to adjust ( -6 minimum / +6 maximum).
Press AUDIO until TRE appears then rotate encoder
left/right to adjust ( -6 minimum / +6 maximum).
Press AUDIO until BAL appears then rotate encoder
left/right to adjust (BAL L 12-BAL 00-BAL R 12).
BAL 00 represents equal balance
Press AUDIO until FAD appears then rotate encoder
left/right to adjust (FAD F 12-FAD 00-FAD R 12).
FAD 00 represents equal fader
Individual Bass and Treble settings are retained in memory
for AM, FM, CD, XM, and AUX modes. This allows you to
save the Bass and Treble settings separately for each mode.
Note:
Any adjustment to the Bass or Treble settings automatically
cancels the current EQ curve (if one is selected).
Press RESET upon initial installation or if abnormal
operation occurs. Refer to page 4 for the reset button
location.
This feature is available when used with the EAUSB20
Media Link Adapter (sold separately).
This feature is available when used with the EAUSB20
Media Link Adapter (sold separately).
This feature is available when used with the EAUSB20
Media Link Adapter (sold separately).
Audio
Bass
Treble
Balance
Fader
Source Audio Memory
Reset
Record
Menu
Return
XDMR7710 OPERATION
General Operation
BASS VOLUME TREBLE BALANCE FADER
