Colorist™ Line 12Qa QRG EN
4
AC Power This product has an auto-ranging power supply that can work with an
input voltage range of 100 to 240 VAC, 50/60 Hz.
To eliminate unnecessary wear and improve its lifespan, during
periods of non-use completely disconnect the product from power via
breaker or by unplugging it.
Power Linking You can link up to 10 Colorist™ Line 12Qa products at 120 V;
18 at 208 V; or 21 at 230 V. Never exceed this number. Power linking
cords can be purchased separately.
IP65 Power Cable
Table
Connection Wire (U.S.) Wire (Europe) IP65 Pin
AC Live Black Brown 1
AC Neutral White Blue 2
AC Ground Green/Yellow Green/Yellow 3
IP65 Power
Connector Pins
When connecting the Colorist™ Line 12Qa to local power, it may be
necessary to use the local-to-IP65 adapters supplied with this
product.
F emale Power IP65 Connector Male Power IP65 Connector
