Ilumiline LΩgic™ 12 RGB
2
What is
Included
• One Ilumiline LΩgic™ 12 RGB
• One Quick Reference Guide
• One CAT5 S plitter
• One Warranty Card
About this
Guide
The
Ilumiline LΩgic™ 12 RGB Quick Reference Guide (QRG) contains
the
product’s features, options, input power, mounting information,
wiring, connectivity, and dimensions.
Refer to the applicable L
Ω gic™ Controller User Manual from the
ILUMINARC
®
website ( www.iluminarc.com ) to learn about the
disclaimers, safety notes, programming modes, and detailed technical
information and instructions.
Product at a
Glance
Use on Dimmer  Auto Programs 
Outdoor Use 
Auto-ranging power
supply

Sound Activated  Replaceable Fuse 
DMX  User Serviceable 
Master/Slave  Duty Cycle 
Features
• RGB LED wash light product
• Compatible with LΩgic™ controllers
• High power 1 W (350 mA) LEDs
• RGB color mixing (with LΩgic™ Controller)
• Extruded aluminum housing (silver)
• Belden 1585A plenum-rated data/power cable (79 in/2 m) with RJ45
connector
• Low power consumption
• IP20 ingress protection
• Lightweight and durable construction
• Plenum-rated cable
Controllers
Please refer to the applicable User Manual to learn more about the L Ω gic™
controllers’ currently available. The User Manuals can be downloaded from
the ILUMINARC
®
website ( www.iluminarc.com ).
•
L
Ωgic™ 1x36
•
L
Ωgic™ 4x36
•
L
Ωgic™ 16x36
