10/100 Auto Negotiation Switch User’s Guide
LEDs
14
Table 6: DES-3224 Full/ Half LED
Status Color Meaning
On Green Port is in Full Duplex
Off Dark Port is in Half Duplex
Utilization LEDs
The Utilization LED indicates the percentage utilization of the CPU during normal operation.
The LED increments from left to right. The farther to the right they are, the greater the
utilization of the CPU. The first six LEDs are green. The last two are amber.
The Utilization LED panel indicates if there is an error on the DES-3224 during the powering
on process and identifies the type of error. See Chapter 6, Troubleshooting, for the System
Error LED Indicators table. The system error table indicates the error code and the
recommended action.
