LV-67L User’s Manual

-

13

-

2.3

2.3.1

Connector

Function

Remark

SO-DIMM 2

LV-67LNB

SO-DIMM 1/2

LV-67LBU

204 -pin DDR3 SO-DIMM socket

SATA 1/2

7-pin Serial ATAIII connector

SATA 3/4/5/6

7-pin Serial ATAII connector

DC_IN

DC 9~24V input connector

24-pin power input connector

ATX P/S Mode

ATX

24-pin power output connector

DC_Input Mode

CN_AUDIO

5 x 2-pin audio connector

CD_IN

4-pin CD-ROM audio input connector

CN_DIO

6 x 2-pin digital I/O connector

CN_USB 3/4/5

5 x 2-pin USB connector

CPUFAN

4-pin CPU cooler fan connector

SYSFAN

3-pin system cooler fan connector

CN_LVDS

20 x 2-pin LVDS connector

CN_DVI

10 x 2-pin DVI connector

CN_INV

5-pin LCD inverter connector

CN_IR

5-pin IrDA connector

CN_COM 4

10-pin RS232

CN_COM 5/6

20-pin 2 x RS232

CN_LPC

5 x 2-pin LPC connector

JFRNT

14-pin front panel switch/indicator
connector

PCIE

164-pin x16 PCIE slot

Mini-PCIE1/2

2 x 52-pin Mini-PCIE socket

JAT

Power mode select

JSPD 1/2

LAN Speed LED connector

JACT 1/2

LAN Activity LED connector

2.3.2

Connector

Function

Remark

USB_RJ45 1/2

2 x USB 3.0 connector for USB 2.0 Interface
and 1 x RJ45 LAN connector

COM1 + CRT

COM1 Connect DB15 and analog VGA connector

COM 2/3

Serial port connector

PS/2

PS/2 keyboard and mouse connector

AUDIO Audio

connector

SPDIF

SPDIF digital audio output connector
