LV-67M
User’s Manual
-17-
CN_LVDS: LVDS 40-pin connector ( Model: HIROSE DF13-40DP-1.25V compatible )
Pin Signal Pin Signal
2 Set by JVLCD 1 Set by JVLCD
4 GND 3 GND
6 A_LVDS_0- 5 B_LVDS_0-
8 A_LVDS_0+ 7 B_LVDS_0+
10 GND 9 GND
12 A_LVDS_1- 11 B_LVDS_1-
14 A_LVDS_1+ 13 B_LVDS_1+
16 GND 15 GND
18 A_LVDS_2- 17 B_LVDS_2-
20 A_LVDS_2+ 19 B_LVDS_2+
22 GND 21 GND
24 A_LVDS_CLK- 23 B_LVDS_3-
26 A_LVDS_CLK+ 25 B_LVDS_3+
28 GND 27 GND
30 A_LVDS_3- 29 B_LVDS_CLK-
32 A_LVDS_3+ 31 B_LVDS_CLK+
34 GND 33 GND
36 LVDS_DDCSCL 35 NC
38 LVDS_DDCSDA 37 NC
40 NC 39 NC
CN_INV: LVDS 5-pin Backlight power header
Pin Signal
1 12V
2 Backlight Control
3 GND
4 GND
5 Enable Backlight
JVLCD: LVDS panel power select jumper
Jumper settings Function
1-2 3.3V (Default)
3-4 5V
5-6 12V
Effective patterns of connection: 1-2 / 3-4 / 5-6
Other may cause damage
