LE-364 User’s Manual Hardware Setup

Onboard Display Interface

2.9

Based on VIA CN400 with built-in S3 Graphics UniChrome Pro IGP graphics, the board

provides onboard VGA display interface, and one 18/24-bit LVDS LCD interface with VIA

VT1631, supports up to 1600 x 1200 of resolution. The two display interfaces can be set

for dual display with extended desktop mode or clone mode.

Below are the main features lists:

128-bit 2D/3D graphics engine

Supports 16 / 32 / 64 MB Frame Buffer sizes (BIOS Selectable)

MPEG-2 hardware VLD (Various Length Decode), iDCT, and motion compensation

for full speed DVD and MPEG-2 playback

MPEG-4 ASP (Advanced Simple Profile) Level 5 with GMC (Global Motion

Compensation) L0/L1 and 1/4-pixel MC support for high video quality and

performance.

2.9.1

The onboard VGA display comes with standard DB15 connector on real I/O panel.

CRT (Analog Display Interface)
