Appendix A
A.1
Connector: IDE
Type: 44-pin (22 x 2) box header
Pin
Description
Pin
Description
1
Reset
2
Ground
3
D7
4
D8
5
D6
6
D9
7
D5
8
D10
9
D4
10
D11
11
D3
12
D12
13
D2
14
D13
15
D1
16
D14
17
D0
18
D15
19
Ground
20
N/C
21
REQ
22
Ground
23
IOW-/STOP
24
Ground
25
IOR-/HDMARDY
26
Ground
27
IORDY/DDMARDY
28
Ground
29
DACK-
30
Ground
31
IRQ
32
N/C
33
A1
34
SD
35
A0
36
A2
37
CS1
38
CS3
39
ASP1
40
Ground
41
Vcc
42
Vcc
43
Ground
44
Ground
A.2
Connector: CN_IR
Type: 5-pin header for SIR Port
Pin
Description
1
VCC
2
N/C
3
IRRX
4
Ground
5
IRTX
2
1
44
43
1
5
