LE-565 User’s Manual Hardware Setup
Connector Reference 15
2.3
2.3.1
Connector Function Remark
DIMM 184-pin DDR SDRAM DIMM Standard
IDE1 40-pin primary IDE connector Standard
IDE2 44-pin secondary IDE connector Slim
FDD 26-pin slim type floppy connector Slim
SATA1/2 7-pin Serial ATA connector Standard
CN_12V 4-pin power supply connector Standard
CN_AUDIO 5 x 2-pin audio connector Standard
CDIN 4-pin CD-ROM audio input connector Standard
CN_DIO 6 x 2-pin digital I/O connector Standard
CN_USB 2/3 5 x 2-pin USB connector Standard
CPUFAN 3-pin CPU cooler fan connector Standard
SYSFAN 3-pin system cooler fan connector Standard
CN_COM2/3/4 5 x 2-pin RS232 serial port Standard
CN_IR 5-pin IrDA connector Standard
CF Compact Flash Type II socket Standard
CN_LVDS 20 x 2-pin LVDS LCD interface Standard
CN_INV 5-pin LCD inverter connector Standard
JLED0/1/2/3 3 x 2-pin LED connector Standard
CN_PWR 4-pin power output connector Standard
PCI Slim 32bit PCI slot Slim
MINIPCI Mini-PCI socket Standard
LPT 13 x 2-pin printer connector Standard
CN_PS2 5 x 2-pin PS2 connector Standard
JFRNT 14-pin switch/indicator connector Standard
2.3.2
Connector Function Remark
CRT DB15 VGA connector Standard
USB Dual USB 2.0 connector Standard
COM1 DB9 Serial port connector Standard
RJ45_1/2/3/4 Four RJ45 LAN connector Standard
DC_IN DC 12V input jack Standard
