HS-771 User’s Manual
-
32
-
2.14
2.14.1
The PS/2 connector supports standard PS/2 keyboard directly or both PS/2 keyboard and mouse
through for PS/2 Y-cable.
Connector: PS2
Type: 6-pin Mini-DIN connector on bracket
Pin
1
2
3
4
5
6
Description KBCLK
MSCLK
Ground
VCC KBDATA MSDATA
2.14.2
Connector: CN_ATKB
Type: 5-pin box header
Pin
1
2
3
4
5
Description VCC Ground N/C KBDATA
KBCLK
PS2
Keyboard
Mouse
CN_ATKB
1
2
3
4
5
6
Female
1
5
1 5
